Python Bindings#

Overview#

OpenImageIO provides Python language bindings for much of its functionality.

You must ensure that the environment variable PYTHONPATH includes the python subdirectory of the OpenImageIO installation.

A Python program must import the OpenImageIO package:

import OpenImageIO

In most of our examples below, we assume that for the sake of brevity, we will alias the package name as follows:

import OpenImageIO as oiio
from OpenImageIO import ImageInput, ImageOutput
from OpenImageIO import ImageBuf, ImageSpec, ImageBufAlgo

TypeDesc#

The TypeDesc class that describes data types of pixels and metadata, described in detail in Section Data Type Descriptions: TypeDesc, is replicated for Python.

class BASETYPE#

The BASETYPE enum corresponds to the C++ TypeDesc::BASETYPE and contains the following values:

UNKNOWN NONE UINT8 INT8 UINT16 INT16 UINT32 INT32 UINT64 INT64
HALF FLOAT DOUBLE STRING PTR

These names are also exported to the OpenImageIO namespace.

class AGGREGATE#

The AGGREGATE enum corresponds to the C++ TypeDesc::AGGREGATE and contains the following values:

SCALAR VEC2 VEC3 VEC4 MATRIX33 MATRIX44

These names are also exported to the OpenImageIO namespace.

class VECSEMANTICS#

The VECSEMANTICS enum corresponds to the C++ TypeDesc::VECSEMANTICS and contains the following values:

NOSEMANTICS COLOR POINT VECTOR NORMAL TIMECODE KEYCODE RATIONAL

These names are also exported to the OpenImageIO namespace.

TypeUnknown TypeString TypeFloat TypeHalf

TypeInt TypeUInt TypeInt16 TypeUInt16

TypeColor TypePoint TypeVector TypeNormal

TypeFloat2 TypeVector2 TypeFloat4

TypeVector2i TypeVector3i

TypeMatrix TypeMatrix33

TypeTimeCode TypeKeyCode TypeRational TypePointer

Pre-constructed TypeDesc objects for some common types, available in the outer OpenImageIO scope.

Example:

t = TypeFloat

str(typedesc)#

Returns a string that describes the TypeDesc.

Example:

print (str(TypeDesc(oiio.UINT16)))

> int16

TypeDesc.basetype#

TypeDesc.aggregate#

TypeDesc.vecsemantics#

TypeDesc.arraylen#

Access to the raw fields in the TypeDesc.

Example:

t = TypeDesc(...)
if t.basetype == oiio.FLOAT :
    print ("It's made of floats")

int TypeDesc.size ()

int TypeDesc.basesize ()

TypeDesc TypeDesc.elementtype ()

int TypeDesc.numelements ()

int TypeDesc.elementsize ()

The size() is the size in bytes, of the type described. The basesize() is the size in bytes of the BASETYPE.

The elementtype() is the type of each array element, if it is an array, or just the full type if it is not an array. The elementsize() is the size, in bytes, of the elementtype (thus, returning the same value as size() if the type is not an array). The numelements() method returns arraylen if it is an array, or 1 if it is not an array.

Example:

t = TypeDesc("point[2]")
print ("size =", t.size())
print ("elementtype =", t.elementtype())
print ("elementsize =", t.elementsize())

> size = 24
> elementtype = point
> elementsize = 12

typedesc == typedesc

typedesc != typedesc

TypeDesc.equivalent(typedesc)#

Test for equality or inequality. The equivalent() method is more forgiving than ==, in that it considers POINT, VECTOR, and NORMAL vector semantics to not constitute a difference from one another.

Example:

f = TypeDesc("float")
p = TypeDesc("point")
v = TypeDesc("vector")
print ("float==point?", (f == p))
print ("vector==point?", (v == p))
print ("float.equivalent(point)?", f.equivalent(p))
print ("vector.equivalent(point)?", v.equivalent(p))

> float==point? False
> vector==point? False
> float.equivalent(point)? False
> vector.equivalent(point)? True

ROI#

The ROI class that describes an image extent or region of interest, explained in detail in Section Rectangular region of interest: ROI, is replicated for Python.

ROI()#

ROI(xbegin, xend, ybegin, yend, zbegin=0, zend=1, chbegin=0, chend=1000)

Construct an ROI with the given bounds. The constructor with no arguments makes an ROI that is “undefined.”

Example:

roi = ROI (0, 640, 0, 480, 0, 1, 0, 4)   # video res RGBA

ROI.xbegin#
ROI.xend#
ROI.ybegin#
ROI.yend#
ROI.zbegin#
ROI.zend#
ROI.chbegin#
ROI.chend#: The basic fields of the ROI (all of type int).

ROI.All#: A pre-constructed undefined ROI understood to mean unlimited ROI on an image.

ROI.defined#: True if the ROI is defined, False if the ROI is undefined.

ROI.width#
ROI.height#
ROI.depth#
ROI.nchannels#: The number of pixels in each dimension, and the number of channels, as described by the ROI. (All of type int.)

int ROI.npixels: The total number of pixels in the region described by the ROI (as an int).

ROI.contains(x, y, z=0, ch=0)#: Returns True if the ROI contains the coordinate.

ROI.contains(other)#: Returns True if the ROI other is entirel contained within this ROI.

ROI get_roi (imagespec)

ROI get_roi_full (imagespec)

Returns an ROI corresponding to the pixel data window of the given ImageSpec, or the display/full window, respectively.

Example:

spec = ImageSpec(...)
roi = oiio.get_roi(spec)

set_roi(imagespec, roi)#

set_roi_full(imagespec, roi)#

Alter the ImageSpec’s resolution and offset to match the passed ROI.

Example:

# spec is an ImageSpec
# The following sets the full (display) window to be equal to the
# pixel data window:
oiio.set_roi_full (spec, oiio.get_roi(spec))

ImageSpec#

The ImageSpec class that describes an image, explained in detail in Section Image Specification: ImageSpec, is replicated for Python.

ImageSpec()#

ImageSpec(typedesc)

ImageSpec(xres, yres, nchannels, typedesc)

ImageSpec(roi, typedesc)

Constructors of an ImageSpec. These correspond directly to the constructors in the C++ bindings.

Example:

import OpenImageIO as oiio
...

# default ctr
s = ImageSpec()

# construct with known pixel type, unknown resolution
s = ImageSpec(oiio.UINT8)

# construct with known resolution, channels, pixel data type
s = ImageSpec(640, 480, 4, "half")

# construct from an ROI
s = ImageSpec (ROI(0,640,0,480,0,1,0,3), TypeFloat)

ImageSpec.width, ImageSpec.height, ImageSpec.depth

ImageSpec.x, ImageSpec.y, ImageSpec.z

Resolution and offset of the image data (int values).

Example:

s = ImageSpec (...)
print ("Data window is ({},{})-({},{})".format (s.x, s.x+s.width-1,
                                                s.y, s.y+s.height-1))

ImageSpec.full_width, ImageSpec.full_height, ImageSpec.full_depth
ImageSpec.full_x, ImageSpec.full_y, ImageSpec.full_z: Resolution and offset of the “full” display window (int values).

ImageSpec.tile_width, ImageSpec.tile_height, ImageSpec.tile_depth: For tiled images, the resolution of the tiles (int values). Will be 0 for untiled images.

ImageSpec.format#: A TypeDesc describing the pixel data.

ImageSpec.nchannels#: An int giving the number of color channels in the image.

ImageSpec.channelnames#: A tuple of strings containing the names of each color channel.

ImageSpec.channelformats#

If all color channels have the same format, that will be ImageSpec.format, and channelformats will be None. However, if there are different formats per channel, they will be stored in channelformats as a tuple of TypeDesc objects.

Example:

if spec.channelformats == None:
    print ("All color channels are", str(spec.format))
else:
    print ("Channel formats: ")
    for t in spec.channelformats:
        print ("\t", t)

ImageSpec.alpha_channel#
ImageSpec.z_channel#: The channel index containing the alpha or depth channel, respectively, or -1 if either one does not exist or cannot be identified.

ImageSpec.deep#: True if the image is a deep (multiple samples per pixel) image, of False if it is an ordinary image.

ImageSpec.extra_attribs#

Direct access to the extra_attribs named metadata, appropriate for iterating over the entire list rather than searching for a particular named value.

len(extra_attribs) : Returns the number of extra attributes.
extra_attribs[i].name : The name of the indexed attribute.
extra_attribs[i].type : The type of the indexed attribute, as a TypeDesc.
extra_attribs[i].value : The value of the indexed attribute.

Example:

s = ImageSpec(...)
...
print ("extra_attribs size is", len(s.extra_attribs))
for i in range(len(s.extra_attribs)) :
    print (i, s.extra_attribs[i].name, str(s.extra_attribs[i].type), " :")
    print ("\t", s.extra_attribs[i].value)
print ()

Imagespec.roi#: The ROI describing the pixel data window.

ImageSpec.roi_full#: The ROI describing the “display window” (or “full size”).

ImageSpec.set_format(typedesc)#

Given a TypeDesc, sets the format field and clear any per-channel formats in channelformats.

Example:

s = ImageSpec ()
s.set_format (TypeDesc("uint8"))

ImageSpec.default_channel_names()#: Sets channel_names to the default names given the value of the nchannels field.

ImageSpec.channelindex(name)#: Return (as an int) the index of the channel with the given name, or -1 if it does not exist.

ImageSpec.channel_bytes()#: ImageSpec.channel_bytes (channel, native=False)} Returns the size of a single channel value, in bytes (as an int). (Analogous to the C++ member functions, see Section Image Specification: ImageSpec for details.)

ImageSpec.pixel_bytes()#
ImageSpec.pixel_bytes(native=False)
ImageSpec.pixel_bytes(chbegin, chend, native=False): Returns the size of a pixel, in bytes (as an int). (Analogous to the C++ member functions, see Section Image Specification: ImageSpec for details.)

ImageSpec.scanline_bytes(native=False)#
ImageSpec.tile_bytes(native=False)#
ImageSpec.image_bytes(native=False)#: Returns the size of a scanline, tile, or the full image, in bytes (as an int). (Analogous to the C++ member functions, see Section Image Specification: ImageSpec for details.)

ImageSpec.tile_pixels()#
ImageSpec.image_pixels()#: Returns the number of pixels in a tile or the full image, respectively (as an int). (Analogous to the C++ member functions, see Section Image Specification: ImageSpec for details.)

ImageSpec.erase_attribute(name, searchtype=TypeUnknown, casesensitive=False)#: Remove any specified attributes matching the regular expression name from the list of extra_attribs.

ImageSpec.attribute(name, int)#

ImageSpec.attribute(name, float)

ImageSpec.attribute(name, string)

ImageSpec.attribute(name, typedesc, data)

Sets a metadata value in the extra_attribs. If the metadata item is a single int, float, or string, you can pass it directly. For other types, you must pass the TypeDesc and then the data (for aggregate types or arrays, pass multiple values as a tuple).

Example:

s = ImageSpec (...)
s.attribute ("foo_str", "blah")
s.attribute ("foo_int", 14)
s.attribute ("foo_float", 3.14)
s.attribute ("foo_vector", TypeDesc.TypeVector, (1, 0, 11))
s.attribute ("foo_matrix", TypeDesc.TypeMatrix,
             (1, 0, 0, 0, 0, 2, 0, 0, 0, 0, 1, 0, 1, 2, 3, 1))

ImageSpec.getattribute(name)#

ImageSpec.getattribute(name, typedesc)

Retrieves a named metadata value from extra_attribs. The generic getattribute() function returns it regardless of type, or None if the attribute does not exist. The typed variety will only succeed if the attribute is actually of that type specified.

Example:

foo = s.getattribute ("foo")   # None if not found
foo = s.getattribute ("foo", oiio.FLOAT)  # None if not found AND float

ImageSpec.get_int_attribute(name, defaultval=0)#

ImageSpec.get_float_attribute(name, defaultval=0.0)#

ImageSpec.get_string_attribute(name, defaultval='')#

ImageSpec.get_bytes_attribute(name, defaultval='')#

Retrieves a named metadata value from extra_attribs, if it is found and is of the given type; returns the default value (or a passed value) if not found.

For an attribute of type STRING, get_bytes_attribute in Python3 skips decoding the underlying C string as UTF-8 and returns a bytes object containing the raw byte string.

Example:

# If "foo" is not found, or if it's not an int, return 0
foo = s.get_int_attribute ("foo")

# If "foo" is not found, or if it's not a string, return "blah"
foo = s.get_string_attribute ("foo", "blah")

ImageSpec[key]

ImageSpec provides a Python dict-like interface for metadata, in addition to attribute() and getattribute().

The ImageSpec["key"] = value notation can be used to set an attribute (just like calling ImageSpec.attribute("key", value)). Also, ImageSpec["key"] can retrieve an attribute if it is present, or raise a KeyError exception if not found.

Like dictionaries, 'key' in spec is True if the attribute is present, and del spec['key'] will remove the attribute.

Examples:

# Same as: spec.attribute("Compression", comp)
spec["Compression"] = comp

# Same as:  comp = spec.getattribute("Compression")
# if it succeeds, or raises a KeyError if not found.
comp = spec["Compression"]

# Failed spec["key"] will raise a KeyError
try:
    r = spec["unknown"]
except:
    print("'unknown' key was not found")

# "key" in spec is True if the key is present
if "Compression" in spec:
    print("'Compression' metadata is present")

# del spec["key"] removes the key
del key["Compression"]

# ImageSpec.get("key") returns the value, or None if not found
comp = spec.get("Compression")
# and optionally, a default value may be passed
comp = spec.get("Compression", "none")

The basic ["key"] setting and retrieval was added in OpenImageIO in 2.1. The "key" in and del operators, and the get() method, were added in OpenImageIO 2.4.

ImageSpec.metadata_val(paramval, human=False)#: For a ParamValue, format its value as a string.

ImageSpec.serialize(format='text', verbose='Detailed')#: Return a string containing the serialization of the ImageSpec. The format may be either “text” or “XML”. The verbose may be one of “brief”, “detailed”, or “detailedhuman”.

ImageSpec.to_xml()#: Equivalent to serialize("xml", "detailedhuman").

ImageSpec.from_xml(xml)#: Initializes the ImageSpec from the information in the string xml containing an XML-serialized ImageSpec.

ImageSpec.channel_name(chan)#: Returns a string containing the name of the channel with index chan.

ImageSpec.channelindex(name)#: Return the integer index of the channel with the given name, or -1 if the name is not a name of one of the channels.

ImageSpec.channelformat(chan)#: Returns a TypeDesc of the channel with index chan.

ImageSpec.get_channelformats()#: Returns a tuple containing all the channel formats.

ImageSpec.valid_tile_range(xbegin, xend, ybegin, yend, zbegin, zend)#: Returns True if the given tile range exactly covers a set of tiles, or False if it isn’t (or if the image is not tiled).

ImageSpec.copy_dimensions(other)#: Copies from ImageSpec other only the fields describing the size and data types, but not the arbitrary named metadata or channel names.

bool ImageSpec.set_colorspace (name)

Set metadata to indicate the presumed color space name, or clear all such metadata if name is the empty string.

This function was added in version 2.5.

Example:

spec = ImageSpec(...)
spec.set_colorspace ("sRGB")

ImageSpec.undefined()#: Returns True for a newly initialized (undefined) ImageSpec.

Example: Header info#

Here is an illustrative example of the use of ImageSpec, a working Python function that opens a file and prints all the relevant header information:

#!/usr/bin/env python
from OpenImageIO import ImageInput

# Print the contents of an ImageSpec
def print_imagespec (spec, subimage=0, mip=0) :
    if spec.depth <= 1 :
        print ("  resolution %dx%d%+d%+d" % (spec.width, spec.height, spec.x, spec.y))
    else :
        print ("  resolution %dx%d%x%d+d%+d%+d" %
               (spec.width, spec.height, spec.depth, spec.x, spec.y, spec.z))
    if (spec.width != spec.full_width or spec.height != spec.full_height
        or spec.depth != spec.full_depth) :
        if spec.full_depth <= 1 :
            print ("  full res   %dx%d%+d%+d" %
                   (spec.full_width, spec.full_height, spec.full_x, spec.full_y))
        else :
            print ("  full res   %dx%d%x%d+d%+d%+d" %
                   (spec.full_width, spec.full_height, spec.full_depth,
                    spec.full_x, spec.full_y, spec.full_z))
    if spec.tile_width :
        print ("  tile size  %dx%dx%d" %
               (spec.tile_width, spec.tile_height, spec.tile_depth))
    else :
        print ("  untiled")
    if mip >= 1 :
        return
    print ("  " + str(spec.nchannels), "channels:", spec.channelnames)
    print ("  format = ", str(spec.format))
    if len(spec.channelformats) > 0 :
        print ("  channelformats = ", spec.channelformats)
    print ("  alpha channel = ", spec.alpha_channel)
    print ("  z channel = ", spec.z_channel)
    print ("  deep = ", spec.deep)
    for i in spec.extra_attribs :
        if type(i.value) == str :
            print (" ", i.name, "= \"" + i.value + "\"")
        else :
            print (" ", i.name, "=", i.value)


def poor_mans_iinfo (filename) :
    input = ImageInput.open (filename)
    if not input :
        print ('Could not open "' + filename + '"')
        print ("\tError: ", oiio.geterror())
        return
    print ('Opened "' + filename + '" as a ' + input.format_name())
    sub = 0
    mip = 0
    while True :
        if sub > 0 or mip > 0 :
            print ("Subimage", sub, "MIP level", mip, ":")
        print_imagespec (input.spec(), mip=mip)
        mip = mip + 1
        if input.seek_subimage (sub, mip) :
            continue    # proceed to next MIP level
        else :
            sub = sub + 1
            mip = 0
            if input.seek_subimage (sub, mip) :
                continue    # proceed to next subimage
        break  # no more MIP levels or subimages
    input.close ()

DeepData#

The DeepData class describing “deep” image data (multiple depth sample per pixel), which is explained in detail in Section Reading “deep” data, is replicated for Python.

DeepData()#: Constructs a DeepData object. It needs to have its init() and alloc() methods called before it can hold any meaningful data.

DeepData.init(npixels, nchannels, channeltypes, channelnames)#: Initializes this DeepData to hold npixels total pixels, with nchannels color channels. The data types of the channels are described by channeltypes, a tuple of TypeDesc values (one per channel), and the names are provided in a tuple of string`s `channelnames. After calling init, you still need to set the number of samples for each pixel (using set_nsamples) and then call alloc() to actually allocate the sample memory.

DeepData.initialized()#: Returns True if the DeepData is initialized at all.

DeepData.allocated()#: Returns True if the DeepData has already had pixel memory allocated.

DeepData.pixels#: This int field contains the total number of pixels in this collection of deep data.

DeepData.channels#: This int field contains the number of channels.

DeepData.A_channel#
DeepData.AR_channel#
DeepData.AG_channel#
DeepData.AB_channel#
DeepData.Z_channel#
DeepData.Zback_channel#: The channel index of certain named channels, or -1 if they don’t exist. For AR_channel, AG_channel, AB_channel, if they don’t exist, they will contain the value of A_channel, and Zback_channel will contain the value of z_channel if there is no actual Zback.

DeepData.channelname(c)#: Retrieve the name of channel C, as a string.

DeepData.channeltype(c)#: Retrieve the data type of channel C, as a TypeDesc.

DeepData.channelsize(c)#: Retrieve the size (in bytes) of one datum of channel C.

DeepData.samplesize()#: Retrieve the packed size (in bytes) of all channels of one sample.

DeepData.same_channeltypes(other)#: Returns True if this DeepData has the same channel types as other.

DeepData.set_samples(pixel, nsamples)#: Set the number of samples for a given pixel (specified by integer index).

DeepData.samples(pixel)#: Get the number of samples for a given pixel (specified by integer index).

DeepData.insert_samples(pixel, samplepos, n)#: Insert n samples starting at the given position of an indexed pixel.

DeepData.erase_samples(pixel, samplepos, n)#: Erase n samples starting at the given position of an indexed pixel.

DeepData.set_deep_value(pixel, channel, sample, value)#: Set specific float value of a given pixel, channel, and sample index.

DeepData.set_deep_value_uint(pixel, channel, sample, value)#: Set specific unsigned int value of a given pixel, channel, and sample index.

DeepData.deep_value(pixel, channel, sample, value)#: Retrieve the specific value of a given pixel, channel, and sample index (for float channels.

DeepData.deep_value_uint(pixel, channel, sample)#: Retrieve the specific value of a given pixel, channel, and sample index (for uint channels).

DeepData.copy_deep_sample(pixel, sample, src, srcpixel, srcsample)#: Copy a deep sample from DeepData src into this DeepData.

DeepData.copy_deep_pixel(pixel, src, srcpixel)#: Copy a deep pixel from DeepData src into this DeepData.

DeepData.split(pixel, depth)#: Split any samples of the pixel that cross depth. Return True if any splits occurred, False if the pixel was unmodified.

DeepData.sort(pixel)#: Sort the samples of the pixel by their Z depth.

DeepData.merge_overlaps(pixel)#: Merge any adjacent samples in the pixel that exactly overlap in z range. This is only useful if the pixel has previously been split at all sample starts and ends, and sorted by depth.

DeepData.merge_deep_pixels(pixel, src, srcpixel)#: Merge the samples of src’s pixel into this DeepData’s pixel.

DeepData.occlusion_cull(pixel)#: Eliminate any samples beyond an opaque sample.

DeepData.opaque_z(pixel)#: For the given pixel index. return the z value at which the pixel reaches full opacity.

ImageInput#

See Chapter ImageInput: Reading Images for detailed explanations of the C++ ImageInput class APIs. The Python APIs are very similar. The biggest difference is that in C++, the various read_* functions write the pixel values into an already-allocated array that belongs to the caller, whereas the Python versions allocate and return an array holding the pixel values (or None if the read failed).

ImageInput.open(filename[, config_imagespec])#

Creates an ImageInput object and opens the named file. Returns the open ImageInput upon success, or None if it failed to open the file (after which, OpenImageIO.geterror() will contain an error message). In the second form, the optional ImageSpec argument config contains attributes that may set certain options when opening the file.

Example:

input = ImageInput.open ("tahoe.jpg")
if input == None :
    print ("Error:", oiio.geterror())
    return

ImageInput.close()#

Closes an open image file, returning True if successful, False otherwise.

Example:

input = ImageInput.open (filename)
...
input.close ()

ImageInput.format_name()#

Returns the format name of the open file, as a string.

Example:

input = ImageInput.open (filename)
if input :
    print (filename, "was a", input.format_name(), "file.")
    input.close ()

ImageInput.spec()#

Returns an ImageSpec corresponding to the currently open subimage and MIP level of the file.

Example:

input = ImageInput.open (filename)
spec = input.spec()
print ("resolution ", spec.width, "x", spec.height)

ImageInput.spec(subimage, miplevel=0)#: Returns a full copy of the ImageSpec corresponding to the designated subimage and MIP level.

ImageSpec ImageInput.spec_dimensions (subimage, miplevel=0): Returns a partial copy of the ImageSpec corresponding to the designated subimage and MIP level, only copying the dimension fields and not any of the arbitrary named metadata (and is thus much less expensive).

ImageInput.current_subimage()#: Returns the current subimage of the file.

ImageInput.current_miplevel()#: Returns the current MIP level of the file.

ImageInput.seek_subimage(subimage, miplevel)#

Repositions the file pointer to the given subimage and MIP level within the file (starting with 0). This function returns True upon success, False upon failure (which may include the file not having the specified subimage or MIP level).

Example:

input = ImageInput.open (filename)
mip = 0
while True :
    ok = input.seek_subimage (0, mip)
    if not ok :
        break
    spec = input.spec()
    print ("MIP level", mip, "is", spec.width, "x", spec.height)

ImageInput.read_image(format='float')#

ImageInput.read_image(chbegin, chend, format='float')

ImageInput.read_image(subimage, miplevel, chbegin, chend, format='float')

Read the entire image and return the pixels as a NumPy array of values of the given format (described by a TypeDesc or a string, float by default). If the format is unknown, the pixels will be returned in the native format of the file. If an error occurs, None will be returned.

For a normal (2D) image, the array returned will be 3D indexed as [y][x][channel]. For 3D volumetric images, the array returned will be 4D with shape indexed as [z][y][x][channel].

Example:

input = ImageInput.open (filename)
spec = input.spec ()
pixels = input.read_image ()
print ("The first pixel is", pixels[0][0])
print ("The second pixel is", pixels[0][1])
input.close ()

ImageInput.read_scanline(y, z, format='float')#

Read scanline number y from depth plane z from the open file, returning the pixels as a NumPy array of values of the given type (described by a TypeDesc or a string, float by default). If the type is TypeUnknown, the pixels will be returned in the native format of the file. If an error occurs, None will be returned.

The pixel array returned will be a 2D ndarray, indexed as [x][channel].

Example:

input = ImageInput.open (filename)
spec = input.spec ()
if spec.tile_width == 0 :
    for y in range(spec.y, spec.y+spec.height) :
        pixels = input.read_scanline (y, spec.z, "float")
        # process the scanline
else :
    print ("It's a tiled file")
input.close ()

ImageInput.read_tile(x, y, z, format='float')#

Read the tile whose upper left corner is pixel (x,y,z) from the open file, returning the pixels as a NumPy array of values of the given type (described by a TypeDesc or a string, float by default). If the type is TypeUnknown, the pixels will be returned in the native format of the file. If an error occurs, None will be returned.

For a normal (2D) image, the array of tile pixels returned will be a 3D ndarray indexed as [y][x][channel]. For 3D volumetric images, the array returned will be 4D with shape indexed as [z][y][x][channel].

Example:

input = ImageInput.open (filename)
spec = input.spec ()
if spec.tile_width > 0 :
    for z in range(spec.z, spec.z+spec.depth, spec.tile_depth) :
        for y in range(spec.y, spec.y+spec.height, spec.tile_height) :
            for x in range(spec.x, spec.x+spec.width, spec.tile_width) :
                pixels = input.read_tile (x, y, z, oiio.FLOAT)
                # process the tile
else :
    print ("It's a scanline file")
input.close ()

ImageInput.read_scanlines(subimage, miplevel, ybegin, yend, z, chbegin, chend, format='float')#

ImageInput.read_scanlines(ybegin, yend, z, chbegin, chend, format='float')

ImageInput.read_tiles(xbegin, xend, ybegin, yend, zbegin, zend, chbegin, chend, format='float')#

ImageInput.read_tiles(subimage, miplevel, xbegin, xend, ybegin, yend, zbegin, zend, format='float')

Similar to the C++ routines, these functions read multiple scanlines or tiles at once, which in some cases may be more efficient than reading each scanline or tile separately. Additionally, they allow you to read only a subset of channels.

For normal 2D images, both read_scanlines and read_tiles will return a 3D array indexed as [z][y][x][channel].

For 3D volumetric images, both read_scanlines will return a 3D array indexed as [y][x][channel], and read_tiles will return a 4D array indexed as [z][y][x][channel],

Example:

input = ImageInput.open (filename)
spec = input.spec ()

# Read the whole image, the equivalent of
#     pixels = input.read_image (type)
# but do it using read_scanlines or read_tiles:
if spec.tile_width == 0 :
    pixels = input.read_scanlines (spec.y, spec.y+spec.height, 0,
                                   0, spec.nchannels)
else :
    pixels = input.read_tiles (spec.x, spec.x+spec.width,
                               spec.y, spec.y+spec.height,
                               spec.z, spec.z+spec.depth,
                               0, spec.nchannels)

ImageInput.read_native_deep_scanlines(subimage, miplevel, ybegin, yend, z, chbegin, chend)#

ImageInput.read_native_deep_tiles(subimage, miplevel, xbegin, xend, ybegin, yend, zbegin, zend, chbegin, chend)#

ImageInput.read_native_deep_image(subimage=0, miplevel=0)#

Read a collection of scanlines, tiles, or an entire image of “deep” pixel data from the specified subimage and MIP level. The begin/end coordinates are all integer values. The value returned will be a DeepData if the read succeeds, or None if the read fails.

These methods are guaranteed to be thread-safe against simultaneous calls to any of the other other read_native calls that take an explicit subimage/miplevel.

ImageInput.get_thumbnail(subimage: int = 0) → ImageBuf#: Retrieve an ImageBuf containing reduced-resolution(“thumbnail”) version of the image. If no thumbnail could be retrieved, an empty ImageBuf will be returned.

ImageInput.geterror(clear=True)#

Retrieves the error message from the latest failed operation on an ImageInput.

Example:

input = ImageInput.open (filename)
if not input :
    print ("Open error:", oiio.geterror())
    # N.B. error on open must be retrieved with the global geterror(),
    # since there is no ImageInput object!
else :
    pixels = input.read_image (oiio.FLOAT)
    if not pixels :
        print ("Read_image error:", input.geterror())
    input.close ()

Example: Reading pixel values from a file to find min/max#

#!/usr/bin/env python
import OpenImageIO as oiio

def find_min_max (filename) :
    input = ImageInput.open (filename)
    if not input :
        print ('Could not open "' + filename + '"')
        print ("\tError: ", oiio.geterror())
        return
    spec = input.spec()
    nchans = spec.nchannels
    pixels = input.read_image()
    if not pixels :
        print ("Could not read:", input.geterror())
        return
    input.close()    # we're done with the file at this point
    minval = pixels[0][0]   # initialize to the first pixel value
    maxval = pixels[0][0]
    for y in range(spec.height) :
        for x in range(spec.width) :
            p = pixels[y][x]
            for c in range(nchans) :
                if p[c] < minval[c] :
                    minval[c] = p[c]
                if p[c] > maxval[c] :
                    maxval[c] = p[c]
    print ("Min values per channel were", minval)
    print ("Max values per channel were", maxval)

ImageOutput#

See Chapter ImageOutput: Writing Images for detailed explanations of the C++ ImageOutput class APIs. The Python APIs are very similar.

ImageOutput.create(name, plugin_searchpath='')#

Create a new ImageOutput capable of writing the named file format (which may also be a file name, with the type deduced from the extension). There is an optional parameter giving an colon-separated search path for finding ImageOutput plugins. The function returns an ImageOutput object, or None upon error (in which case, OpenImageIO.geterror() may be used to retrieve the error message).

Example:

import OpenImageIO as oiio
output = ImageOutput.create ("myfile.tif")
if not output :
    print ("Error:", oiio.geterror())

ImageOutput.format_name()#

The file format name of a created ImageOutput, as a string.

Example:

output = ImageOutput.create (filename)
if output :
    print ("Created output", filename, "as a", output.format_name()

ImageOutput.supports(feature)#

For a created ImageOutput, returns True if the file format supports the named feature (such as “tiles”, “mipmap”, etc., see Section ImageOutput Class Reference for the full list), or False if this file format does not support the feature.

Example:

output = ImageOutput.create (filename)
if output :
    print (output.format_name(), "supports...")
    print ("tiles?", output.supports("tiles"))
    print ("multi-image?", output.supports("multiimage"))
    print ("MIP maps?", output.supports("mipmap"))
    print ("per-channel formats?", output.supports("channelformats"))

ImageOutput.open(filename, spec, mode='Create')#

Opens the named output file, with an ImageSpec describing the image to be output. The mode may be one of “Create”, “AppendSubimage”, or “AppendMIPLevel”. See Section ImageOutput Class Reference for details. Returns True upon success, False upon failure (error messages retrieved via ImageOutput.geterror().)

Returns:: True for success, False for failure.

Example:

output = ImageOutput.create (filename)
if not output :
    print ("Error:", oiio.geterror())
spec = ImageSpec (640, 480, 3, "uint8")
ok = output.open (filename, spec)
if not ok :
    print ("Could not open", filename, ":", output.geterror())

ImageOutput.open(filename, (imagespec, ...))#

This variety of open() is used specifically for multi-subimage files. A tuple of ImageSpec objects is passed, one for each subimage that will be written to the file. After each subimage is written, then a regular call to open(name, newspec, AppendSubimage) moves on to the next subimage.

Returns:: True for success, False for failure.

ImageOutput.close()#

Closes an open output.

Returns:: True for success, False for failure.

ImageOutput.spec()#: Returns the ImageSpec of the currently-open output image.

ImageOutput.write_image(pixels)#

Write the currently opened image all at once. The pixels parameter should be a Numpy ndarray containing data elements indexed as [y][x][channel] for normal 2D images, or for 3D volumetric images, as [z][y][x][channel], in other words, exactly matching the shape of array returned by ImageInput.read_image(). (It will also work fine if the array is 1D “flattened” version, as long as it contains the correct total number of values.) The data type is deduced from the contents of the array itself. Returns True upon success, False upon failure.

Example:

# This example reads a scanline file, then converts it to tiled
# and writes to the same name.

input = ImageInput.open (filename)
spec = input.spec ()
pixels = input.read_image ()
input.close ()

output = ImageOutput.create (filename)
if output.supports("tiles") :
    spec.tile_width = 64
    spec.tile_height = 64
    output.open (filename, spec)
    output.write_image (pixels)
    output.close ()

ImageOutput.write_scanline(y, z, pixels)#

ImageOutput.write_scanlines(ybegin, yend, z, pixels)#

Write one or many scanlines to the currently open file. Returns True upon success, False upon failure.

The pixels parameter should be a Numpy ndarray containing data elements indexed as [x][channel] for write_scanline or as [y][x][channels for write_scanlines, exactly matching the shape returned by ImageInput.read_scanline or ImageInput.read_scanlines. (It will also work fine if the array is 1D “flattened” version, as long as it contains the correct total number of values.)

Example:

# Copy a TIFF image to JPEG by copying scanline by scanline.
input = ImageInput.open ("in.tif")
spec = input.spec ()
output = ImageOutput.create ("out.jpg")
output.open (filename, spec)
for z in range(spec.z, spec.z+spec.depth) :
    for y in range(spec.y, spec.y+spec.height) :
        pixels = input.read_scanline (y, z)
        output.write_scanline (y, z, pixels)
output.close ()
input.close ()

# The same example, but copying a whole "plane" of scanlines at a time:
...
for z in range(spec.z, spec.z+spec.depth) :
    pixels = input.read_scanlines (spec.y, spec.y+spec.height, z)
    output.write_scanlines (spec.y, spec.y+spec.height, z, pixels)
...

ImageOutput.write_tile(x, y, z, pixels)#

ImageOutput.write_tiles(xbegin, xend, ybegin, yend, zbegin, zend, pixels)#

Write one or many tiles to the currently open file. Returns True upon success, False upon failure.

The pixels parameter should be a Numpy ndarray containing data elements indexed as [y][x][channel] for normal 2D images, or as [z][y][x][channels 3D volumetric images, exactly matching the shape returned by ImageInput.read_tile or ImageInput.read_tiles. (It will also work fine if the array is 1D “flattened” version, as long as it contains the correct total number of values.)

Example:

input = ImageInput.open (in_filename)
spec = input.spec ()
output = ImageOutput.create (out_filename)
output.open (out_filename, spec)
for z in range(spec.z, spec.z+spec.depth, spec.tile_depth) :
    for y in range(spec.y, spec.y+spec.height, spec.tile_height) :
        for x in range(spec.x, spec.x+spec.width, spec.tile_width) :
            pixels = input.read_tile (x, y, z)
            output.write_tile (x, y, z, pixels)
output.close ()
input.close ()

# The same example, but copying a whole row of of tiles at a time:
...
for z in range(spec.z, spec.z+spec.depth, spec.tile_depth) :
    for y in range(spec.y, spec.y+spec.height, spec.tile_height) :
        pixels = input.read_tiles (spec.x, spec.x+spec.width,
                                   y, y+tile_width, z, z+tile_width)
        output.write_tiles (spec.x, spec.x+spec.width,
                            y, y+tile_width, z, z+tile_width, pixels)
...

ImageOutput.write_deep_scanlinesa(ybegin, yend, z, deepdata)#
ImageOutput.write_deep_tiles(xbegin, xend, ybegin, yend, zbegin, zend, deepdata)#
ImageOutput.write_deep_image(deepdata)#: Write a collection of scanlines, tiles, or an entire image of “deep” pixel data. The begin/end coordinates are all integer values, and deepdata should be a DeepData.

ImageOutput.set_thumbnail(thumb: ImageBuf)#: Specify a reduced-resolution (“thumbnail”) version of the image, as an ImageBuf. Note that many image formats may require the thumbnail to be specified prior to writing the pixels. Return True for success, or False if a thumbnail could not be set.

ImageOutput.copy_image(imageinput)#

Copy the current image of the open input to the open output. (The reason this may be preferred in some circumstances is that, if input and output were the same kind of input file format, they may have a special efficient technique to copy pixels unaltered, for example by avoiding the decompression/recompression round trip.)

Example:

input = ImageInput.open (in_filename)
spec = input.spec ()
output = ImageOutput.create (out_filename)
output.open (filename, spec)
output.copy_image (input)
output.close ()
input.close ()

ImageOuput.geterror(clear=True)#

Retrieves the error message from the latest failed operation on an open file.

Example:

output = ImageOutput.create (filename)
if not output :
    print ("Create error:", oiio.geterror())
    # N.B. error on create must be retrieved with the global geterror(),
    # since there is no ImageOutput object!
else :
    ok = output.open (filename, spec)
    if not ok :
        print ("Open error:", output.geterror())
    ok = output.write_image (pixels)
    if not ok :
        print ("Write error:", output.geterror())
    output.close ()

ImageBuf#

See Chapter ImageBuf: Image Buffers for detailed explanations of the C++ ImageBuf class APIs. The Python APIs are very similar.

ImageBuf()#

Construct a new, empty ImageBuf. The ImageBuf is uninitialized and is awaiting a call to reset() or copy() before it is useful.

ImageBuf(filename[, subimage, miplevel])#

Construct a read-only ImageBuf that will read from the named file. Optionally, a specific subimage or MIP level may be specified (defaulting to 0).

Example:

import OpenImageIO as oiio
...
buf = ImageBuf ("grid.tif")

ImageBuf(filename, subimage, miplevel, config)#

Construct a read-only ImageBuf that will read from the named file, with an ImageSpec config giving configuration hints.

Example:

import OpenImageIO as oiio
...
config = ImageSpec()
config.attribute("oiio:RawColor", 1)
buf = ImageBuf ("grid.tif", 0, 0, config)

ImageBuf(imagespec, zero=True)#

Construct a writable ImageBuf of the dimensions and data format specified by an ImageSpec. The pixels will be initialized to black/empty values if zero is True, otherwise the pixel values will remain uninitialized.

Example:

spec = ImageSpec (640, 480, 3, "float")
buf = ImageBuf (spec)

ImageBuf(data)#

Construct a writable ImageBuf of the dimensions of data, which is a NumPy ndarray of values indexed as [y][x][channel] for normal 2D images, or for 3D volumetric images, as [z][y][x][channel]. The data will be copied into the ImageBuf’s internal storage. The NumPy array may be strided for z, y, or x, but must have “contiguous” channel data within each pixel. The pixel data type is also deduced from the contents of the data array.

Note that this Python ImageBuf will contain its own copy of the data, so further changes to the data array will not affect the ImageBuf. This is different from the C++ ImageBuf constructor from a pointer, which will “wrap” the existing user-provided buffer but not make its own copy.

Example:

pixels = numpy.zeros ((640, 480, 3), dtype = numpy.float32)
buf = ImageBuf (pixels)

ImageBuf.clear()#

Resets the ImageBuf to a pristine state identical to that of a freshly constructed ImageBuf using the default constructor.

Example:

buf = ImageBuf (...)

# The following two commands are equivalent:
buf = ImageBuf()     # 1 - assign a new blank ImageBuf
buf.clear()          # 2 - clear the existing ImageBuf

ImageBuf.reset(filename, subimage=0, miplevel=0, config=ImageSpec())#: Restore the ImageBuf to a newly-constructed state, to read from a filename (optionally specifying a subimage, MIP level, and/or a “configuration” ImageSpec).

ImageBuf.reset(imagespec, zero=True)#: Restore the ImageBuf to the newly-constructed state of a writable ImageBuf specified by an ImageSpec. The pixels will be iniialized to black/empty if zero is True, otherwise the pixel values will remain uninitialized.

ImageBuf.reset(data)#

Reset the ImageBuf to be sized to the dimensions of data, which is a NumPy ndarray of values indexed as [y][x][channel] for normal 2D images, or for 3D volumetric images, as [z][y][x][channel]. The data will be copied into the ImageBuf’s internal storage. The NumPy array may be strided for z, y, or x, but must have “contiguous” channel data within each pixel. The pixel data type is also deduced from the contents of the data array.

ImageBuf.read(subimage=0, miplevel=0, force=False, convert=oiio.UNKNOWN)#

ImageBuf.read(subimage, miplevel, chbegin, chend, force, convert)

Explicitly read the image from the file (of a file-reading ImageBuf), optionally specifying a particular subimage, MIP level, and channel range. If force is True, will force an allocation of memory and a full read (versus the default of relying on an underlying ImageCache). If convert is not the default of`UNKNOWN`, it will force the ImageBuf to convert the image to the specified data format (versus keeping it in the native format or relying on the ImageCache to make a data formatting decision).

Note that a call to read() is not necessary — any ImageBuf API call that accesses pixel values will trigger a file read if it has not yet been done. An explicit read() is generally only needed to change the subimage or miplevel, or to force an in-buffer read or format conversion.

The read() method will return True for success, or False if the read could not be performed (in which case, a geterror() call will retrieve the specific error message).

Example:

buf = ImageBuf ("mytexture.exr")
buf.read (0, 2, True)
# That forces an allocation and read of MIP level 2

ImageBuf.init_spec(filename, subimage=0, miplevel=0)#

Explicitly read just the header from a file-reading ImageBuf (if the header has not yet been read), optionally specifying a particular subimage and MIP level. The init_spec() method will return True for success, or False if the read could not be performed (in which case, a geterror() call will retrieve the specific error message).

Note that a call to init_spec() is not necessary — any ImageBuf API call that accesses the spec will read it automatically it has not yet been done.

ImageBuf.write(filename, dtype='', fileformat='')#

Write the contents of the ImageBuf to the named file. Optionally, dtype can override the pixel data type (by default, the pixel data type of the buffer), and fileformat can specify a particular file format to use (by default, it will infer it from the extension of the file name).

Example:

# No-frills conversion of a TIFF file to JPEG
buf = ImageBuf ("in.tif")
buf.write ("out.jpg")

# Convert to uint16 TIFF
buf = ImageBuf ("in.exr")
buf.write ("out.tif", "uint16")

ImageBuf.write(imageoutput)#

Write the contents of the ImageBuf as the next subimage to an open ImageOutput.

Example:

buf = ImageBuf (...)   # Existing ImageBuf

out = ImageOutput.create("out.exr")
out.open ("out.exr", buf.spec())

buf.write (out)
out.close()

ImageBuf.make_writable(keep_cache_type=False)#: Force the ImageBuf to be writable. That means that if it was previously backed by an ImageCache (storage was IMAGECACHE), it will force a full read so that the whole image is in local memory.

ImageBuf.set_write_format(format=oiio.UNKNOWN)#

ImageBuf.set_write_tiles(width=0, height=0, depth=0)#

Override the data format or tile size in a subsequent call to write(). The format argument to set_write_format may be either a single data type description for all channels, or a tuple giving the data type for each channel in order.

Example:

# Conversion to a tiled unsigned 16 bit integer file
buf = ImageBuf ("in.tif")
buf.set_write_format ("uint16")
buf.set_write_tiles (64, 64)
buf.write ("out.tif")

ImageBuf.spec()#

ImageBuf.nativespec()#

ImageBuf.spec() returns the ImageSpec that describes the contents of the ImageBuf. ImageBuf.nativespec() returns an ImageSpec that describes the contents of the file that the ImageBuf was read from (this may differ from ImageBuf.spec() due to format conversions, or any changes made to the ImageBuf after the file was read, such as adding metadata).

Handy rule of thumb: spec() describes the buffer, nativespec() describes the original file it came from.

Example:

buf = ImageBuf ("in.tif")
print ("Resolution is", buf.spec().width, "x", buf.spec().height)

ImageBuf.specmod()#

ImageBuf.specmod() provides a reference to the writable ImageSpec inside the ImageBuf. Be very careful! It is safe to modify certain metadata, but if you change the data format or resolution fields, you will get the chaos you deserve.

Example:

# Read an image, add a caption metadata, write it back out in place
buf = ImageBuf ("file.tif")
buf.specmod().attribute ("ImageDescription", "my photo")
buf.write ("file.tif")

ImageBuf.has_thumbnail#: Contains True if the ImageBuf contains thumbnail data, otherwise False.

ImageBuf.clear_thumbnail()#: Remove any associated thumbnail from this buffer.

ImageBuf.set_thumbnail(thumb: ImageBuf)#: Set the thumbnai associated with this buffer to thumb.

ImageBuf.thumbnail() → ImageBuf#: Return an ImageBuf holding any thumbnail associated with this buffer.

ImageBuf.name#: The file name of the image (as a string).

ImageBuf.file_format_name#: The file format of the image (as a string).

ImageBuf.subimage#
ImageBuf.miplevel#
ImageBuf.nsubimages#
ImageBuf.nmiplevels#: Several fields giving information about the current subimage and MIP level, and the total numbers thereof in the file.

ImageBuf.xbegin#
ImageBuf.xend#
ImageBuf.ybegin#
ImageBuf.yend#
ImageBuf.zbegin#
ImageBuf.zend#: The range of valid pixel data window. Remember that the end is one past the last pixel.

ImageBuf.xmin#
ImageBuf.xmax#
ImageBuf.ymin#
ImageBuf.ymax#
ImageBuf.zmin#
ImageBuf.zmax#: The minimum and maximum (inclusive) coordinates of the pixel data window.

ImageBuf.orientation#

ImageBuf.oriented_width#

ImageBuf.oriented_height#

ImageBuf.oriented_x#

ImageBuf.oriented_y#

ImageBuf.oriented_full_width#

ImageBuf.oriented_full_height#

ImageBuf.oriented_full_x#

ImageBuf.oriented_full_y#

The Orientation field gives the suggested display oriententation of the image (see Section Display hints).

The other fields are helpers that give the width, height, and origin (as well as “full” or “display” resolution and origin), taking the intended orientation into consideration.

ImageBuf.roi#

ImageBuf.roi_full#

These fields hold an ROI description of the pixel data window (roi) and the full (a.k.a. “display”) window (roi_full).

Example:

buf = ImageBuf ("tahoe.jpg")
print ("Resolution is", buf.roi.width, "x", buf.roi.height)

ImageBuf.set_origin(x, y, z=0)#

Changes the “origin” of the data pixel data window to the specified coordinates.

Example:

# Shift the pixel data so the upper left is at pixel (10, 10)
buf.set_origin (10, 10)

ImageBuf.set_full(xbegin, xend, ybegin, yend, zbegin, zend)#

Changes the “full” (a.k.a. “display”) window to the specified ROI.

Example:

buf.set_full (0, 1024, 0, 768, 0, 1)

ImageBuf.pixels_valid#: Will be True if the file has already been read and the pixels are valid. (It is always True for writable ImageBuf’s.) There should be few good reasons to access these, since the spec and pixels will be automatically be read when they are needed.

ImageBuf.pixeltype()#: Returns a TypeDesc describing the data type of the pixels stored within the ImageBuf.

ImageBuf.copy_metadata(other_imagebuf)#: Replaces the metadata (all ImageSpec items, except for the data format and pixel data window size) with the corresponding metadata from the other ImageBuf.

ImageBuf.copy_pixels(other_imagebuf)#: Replace the pixels in this ImageBuf with the values from the other ImageBuf.

ImageBuf ImageBuf.copy (format=TypeUnknown)

Return a full copy of this ImageBuf (with optional data format conversion, if format is supplied).

Example:

A = ImageBuf("A.tif")

# Make a separate, duplicate copy of A
B = A.copy()

# Make another copy of A, but converting to float pixels
C = A.copy ("float")

ImageBuf.copy(other_imagebuf, format=TypeUnknown)#

Make this ImageBuf a complete copy of the other ImageBuf. If a format is provided, this will get the specified pixel data type rather than using the same pixel format as the source ImageBuf.

Example:

A = ImageBuf("A.tif")

# Make a separate, duplicate copy of A
B = ImageBuf()
B.copy (A)

# Make another copy of A, but converting to float pixels
C = ImageBuf()
C.copy (A, oiio.FLOAT)

ImageBuf.swap(other_imagebuf)#

Swaps the content of this ImageBuf and the other ImageBuf.

Example:

A = ImageBuf("A.tif")
B = ImageBuf("B.tif")
A.swap (B)
# Now B contains the "A.tif" image and A contains the "B.tif" image

tuple ImageBuf.getpixel (x, y, z=0, wrap="black")

Retrieves pixel (x,y,z) from the buffer and return it as a tuple of float values, one for each color channel. The x, y, z values are int pixel coordinates. The optional wrap parameter describes what should happen if the coordinates are outside the pixel data window (and may be: “black”, “clamp”, “periodic”, “mirror”).

Example:

buf = ImageBuf ("tahoe.jpg")
p = buf.getpixel (50, 50)
print (p)

> (0.37, 0.615, 0.97)

ImageBuf.getchannel(x, y, z, channel, wrap='black')#

Retrieves just a single channel value from pixel (x,y,z) from the buffer and returns it as a float value. The optional wrap parameter describes what should happen if the coordinates are outside the pixel data window (and may be: “black”, “clamp”, “periodic”, “mirror”).

Example:

buf = ImageBuf ("tahoe.jpg")
green = buf.getchannel (50, 50, 0, 1)

ImageBuf.interppixel(x, y, wrap='black')#

ImageBuf.interppixel_bicubic(x, y, wrap='black')#

Interpolates the image value (bilinearly or bicubically) at coordinates $(x,y)$ and return it as a tuple of float values, one for each color channel. The x, y values are continuous float coordinates in “pixel space.” The optional wrap parameter describes what should happen if the coordinates are outside the pixel data window (and may be: “black”, “clamp”, “periodic”, “mirror”).

Example:

buf = ImageBuf ("tahoe.jpg")
midx = float(buf.xbegin + buf.xend) / 2.0
midy = float(buf.ybegin + buf.yend) / 2.0
p = buf.interpixel (midx, midy)
# Now p is the interpolated value from right in the center of
# the data window

ImageBuf.interppixel_NDC(x, y, wrap='black')#

ImageBuf.interppixel_bicubic_NDC(x, y, wrap='black')#

Interpolates the image value (bilinearly or bicubically) at coordinates (x,y) and return it as a tuple of float values, one for each color channel. The x, y values are continuous, normalized float coordinates in “NDC space,”” where (0,0) is the upper left corner of the full (a.k.a. “display”) window, and (1,1) is the lower right corner of the full/display window. The wrap parameter describes what should happen if the coordinates are outside the pixel data window (and may be: “black”, “clamp”, “periodic”, “mirror”).

Example:

buf = ImageBuf ("tahoe.jpg")
p = buf.interpixel_NDC (0.5, 0.5)
# Now p is the interpolated value from right in the center of
# the display window

ImageBuf.setpixel(x, y, pixel_value)#

ImageBuf.setpixel(x, y, z, pixel_value)

Sets pixel (x,y,z) to be the pixel_value, expressed as a tuple of float (one for each color channel).

Example:

buf = ImageBuf (ImageSpec (640, 480, 3, oiio.UINT8))

# Set the whole image to red (the dumb slow way, but it works):
for y in range(buf.ybegin, buf.yend) :
    for x in range(buf.xbegin, buf.xend) :
        buf.setpixel (x, y, (1.0, 0.0, 0.0))

ImageBuf.get_pixels(format=TypeFloat, roi=ROI.All)#

Retrieves the rectangle of pixels (and channels) specified by roi from the image and returns them as an array of values with type specified by format.

As with the ImageInput read functions, the return value is a NumPy ndarray containing data elements indexed as [y][x][channel] for normal 2D images, or for 3D volumetric images, as [z][y][x][channel]). Returns True upon success, False upon failure.

Example:

buf = ImageBuf ("tahoe.jpg")
pixels = buf.get_pixels (oiio.FLOAT)  # no ROI means the whole image

ImageBuf.set_pixels(roi, data)#

Sets the rectangle of pixels (and channels) specified by roi with values in the data, which is a NumPy ndarray of values indexed as [y][x][channel] for normal 2D images, or for 3D volumetric images, as [z][y][x][channel]. (It will also work fine if the array is 1D “flattened” version, as long as it contains the correct total number of values.) The data type is deduced from the contents of the array itself.

Example:

buf = ImageBuf (...)
pixels = (....)
buf.set_pixels (ROI(), pixels)

ImageBuf.has_error#: This field will be True if an error has occurred in the ImageBuf.

ImageBuf.geterror(clear=True)#

Retrieve the error message (and clear the has_error flag).

Example:

buf = ImageBuf ("in.tif")
buf.read ()   # force a read
if buf.has_error :
    print ("Error reading the file:", buf.geterror())
buf.write ("out.jpg")
if buf.has_error :
    print ("Could not convert the file:", buf.geterror())

ImageBuf.pixelindex(x, y, z, check_range=False)#: Return the index of pixel (x,y,z).

ImageBuf.deep#: Will be True if the file contains “deep” pixel data, or False for an ordinary images.

ImageBuf.deep_samples(x, y, z=0)#: Return the number of deep samples for pixel (x,y,z).

ImageBuf.set_deep_samples(x, y, z, nsamples)#: Set the number of deep samples for pixel (x,y,z).

ImageBuf.deep_insert_samples(x, y, z, samplepos, nsamples)#
ImageBuf.deep_erase_samples(x, y, z, samplepos, nsamples)#: Insert or erase nsamples samples starting at the given position of pixel (x,y,z).

ImageBuf.deep_value(x, y, z, channel, sample)#
ImageBuf.deep_value_uint(x, y, z, channel, sample)#: Return the value of the given deep sample (particular pixel, channel, and sample number) for a channel that is a float or an unsigned integer type, respectively.

ImageBuf.set_deep_value(x, y, z, channel, sample, value)#
ImageBuf.set_deep_value_uint(x, y, z, channel, sample, value)#: Set the value of the given deep sample (particular pixel, channel, and sample number) for a channel that is a float or an unsigned integer type, respectively.

DeepData ImageBuf.deepdata: A reference to the underlying DeepData of the image.

ImageBufAlgo#

The C++ ImageBufAlgo functions are described in detail in Chapter ImageBufAlgo: Image Processing. They are also exposed to Python. For the majority of ImageBufAlgo functions, their use in Python is identical to C++; in those cases, we will keep our descriptions of the Python bindings minimal and refer you to Chapter ImageBufAlgo: Image Processing, saving the extended descriptions for those functions that differ from the C++ counterparts.

A few things about the parameters of the ImageBufAlgo function calls are identical among the functions, so we will explain once here rather than separately for each function:

dst is an existing ImageBuf, which will be modified (it may be an uninitialized ImageBuf, but it must be an ImageBuf).
src parameter is an initialized ImageBuf, which will not be modified (unless it happens to refer to the same image as dst.
roi, if supplied, is an roi specifying a region of interest over which to operate. If omitted, the region will be the entire size of the source image(s).
nthreads is the maximum number of threads to use. If not supplied, it defaults to 0, meaning to use as many threads as hardware cores available.

Just as with the C++ ImageBufAlgo functions, if dst is an uninitialized ImageBuf, it will be sized to reflect the roi (which, in turn, if undefined, will be sized to be the union of the ROI’s of the source images).

Pattern generation#

ImageBuf ImageBufAlgo.zero (roi, nthreads=0)

ImageBufAlgo.zero(dst, roi=ROI.All, nthreads=0)#

Zero out the destination buffer (or a specific region of it).

Example:

# Initialize buf to a 640x480 3-channel FLOAT buffer of 0 values
buf = ImageBufAlgo.zero (ROI(0, 640, 0, 480, 0, 1, 0, 3))

ImageBuf ImageBufAlgo.fill (values, roi=ROI.All, nthreads=0)

ImageBuf ImageBufAlgo.fill (top, bottom, roi=ROI.All, nthreads=0)

ImageBuf ImageBufAlgo.fill (topleft, topright, bottomleft, bottomright, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.fill (dst, values, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.fill (dst, top, bottom, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.fill (dst, topleft, topright, bottomleft, bottomright, roi=ROI.All, nthreads=0)

Return a filled float image of size roi, or set the the pixels of image dst within the ROI to a color or gradient.

Three fill optins are available: (a) if one color tuple is supplied, the whole ROI will be filled with that constant value, (b) if two color tuples are supplied, a linear gradient will be applied from top to bottom, (c) if four color cuples are supplied, the ROI will be be filled with values bilinearly interpolated from the four corner colors supplied.

Example:

# Draw a red rectangle into buf
buf = ImageBuf (ImageSpec(640, 480, 3, TypeDesc.FLOAT)
ImageBufAlgo.fill (buf, (1,0,0), ROI(50, 100, 75, 85))

ImageBuf ImageBufAlgo.checker(width, height, depth, color1, color2, xoffset=0, yoffset=0, zoffset=0, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.checker(dst, width, height, depth, color1, color2, xoffset=0, yoffset=0, zoffset=0, roi=ROI.All, nthreads=0)

Return (or copy into dst) a checkerboard pattern. The colors are specified as tuples giving the values for each color channel.

Example:

buf = ImageBuf(ImageSpec(640, 480, 3, oiio.UINT8))
ImageBufAlgo.checker (buf, 64, 64, 1, (0.1,0.1,0.1), (0.4,0.4,0.4))

ImageBuf ImageBufAlgo.noise (noisetype, A=0.0, B=0.1, mono=False, seed=0, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.noise (dst, noisetype, A=0.0, B=0.1, mono=False, seed=0, roi=ROI.All, nthreads=0)

Return an image of pseudorandom noise, or add pseudorandom noise to the specified region of existing region dst.

For noise type “white” (and its synonym “uniform”), the values are uniformly distributed on the range [A,B) and independently chosen for each pixel. For noise type “blue”, the range will still be uniformly distributed on [A,B) as with “white,” except that the values have better spectral properties for sampling and dithering purposes. For noise “gaussian”, the noise will have a normal distribution with mean A and standard deviation B. For noise “salt”, the value A will be stored in a random set of pixels whose proportion (of the overall image) is B.

For all noise types, choosing different seed values will result in a different pattern. If the mono flag is True, a single noise value will be applied to all channels specified by roi, but if mono is False, a separate noise value will be computed for each channel in the region.

Example:

buf = ImageBuf(ImageSpec(640, 480, 3, oiio.UINT8))
ImageBufAlgo.zero (buf)
ImageBufAlgo.noise (buf, 'white', 0.25, 0.75)

ImageBuf ImageBufAlgo.bluenoise_image ()

Return a reference to a singleton ImageBuf containing a 4-channel float periodic blue noise image.

Example:

buf = ImageBufAlgo.bluenoise_image ()

ImageBufAlgo.render_point(dst, x, y, color=(1, 1, 1, 1))#

Render a point at pixel (x,y) of dst. The color (if supplied) is a tuple giving the per-channel colors. Return True for success, False for failure.

Example:

buf = ImageBuf(ImageSpec (640, 480, 4, oiio.FLOAT))
ImageBufAlgo.render_point (buf, 10, 20, (1,0,0,1))

bool ImageBufAlgo.render_line (dst, x1, y1, x2, y2, color=(1,1,1,1), skip_first_point=False)

Render a line from pixel $(x_1,y_1)$ to $(x_2,y_2)$ into dst. The color (if supplied) is a tuple giving the per-channel colors.

Example:

buf = ImageBuf(ImageSpec (640, 480, 4, oiio.FLOAT))
ImageBufAlgo.render_line (buf, 10, 10, 500, 20, (1,0,0,1))

bool ImageBufAlgo.render_box (dst, x1, y1, x2, y2, color=(1,1,1,1), filled=False)

Render a filled or unfilled box with corners at pixels $(x_1,y_1)$ and $(x_2,y_2)$ into dst. The color (if supplied) is a tuple giving the per-channel colors.

Example:

buf = ImageBuf(ImageSpec (640, 480, 4, oiio.FLOAT))
ImageBufAlgo.render_box (buf, 150, 100, 240, 180, (0,1,1,1))
ImageBufAlgo.render_box (buf, 100, 50, 180, 140, (0.5, 0.5, 0, 0.5), True)

bool ImageBufAlgo.render_text (dst, x, y, text, fontsize=16, fontname="", textcolor=(1,1,1,1), alignx="left", aligny="baseline", shadow=0, roi=ROI.All, nthreads=0)

Render antialiased text into dst. The textcolor (if supplied) is a tuple giving the per-channel colors. Choices for alignx are “left”, “right”, and “center”, and choices for aligny are “baseline”, “top”, “bottom”, and “center”.

Example:

buf = ImageBuf(ImageSpec (640, 480, 4, oiio.FLOAT))
ImageBufAlgo.render_text (buf, 50, 100, "Hello, world")
ImageBufAlgo.render_text (buf, 100, 200, "Go Big Red!",
                          60, "Arial Bold", (1,0,0,1))

ROI ImageBufAlgo.text_size (text, fontsize=16, fontname="")

Compute the size that will be needed for the text as an ROI and return it. The size will not be defined if an error occurred (such as not being a valid font name).

Example:

A = ImageBuf(ImageSpec (640, 480, 4, oiio.FLOAT))
Aroi = A.roi
size = ImageBufAlgo.text_size ("Centered", 40, "Courier New")
if size.defined :
    x = Aroi.xbegin + Aroi.width/2  - (size.xbegin + size.width/2)
    y = Aroi.ybegin + Aroi.height/2 - (size.ybegin + size.height/2)
    ImageBufAlgo.render_text (A, x, y, "Centered", 40, "Courier New")

# Note: this was for illustration. An easier way to do this is:
#   render_text (A, x, y, "Centered", 40, "Courier New", alignx="center")

Image transformations and data movement#

ImageBuf ImageBufAlgo.channels(src, channelorder, newchannelnames=(), shuffle_channel_names=False, nthreads=0)

bool ImageBufAlgo.channels(dst, src, channelorder, newchannelnames=(), shuffle_channel_names=False, nthreads=0)

Return (or store in dst) shuffled channels of src, with channels in the order specified by the tuple channelorder. The length of channelorder specifies the number of channels to copy. Each element in the tuple channelorder may be one of the following:

int : specifies the index (beginning at 0) of the channel to copy.
str : specifies the name of the channel to copy.
float : specifies a constant value to use for that channel.

If newchannelnames is supplied, it is a tuple of new channel names. (See the C++ version for more full explanation.)

Example:

# Copy the first 3 channels of an RGBA, drop the alpha
RGBA = ImageBuf("rgba.tif")
RGB = ImageBufAlgo.channels (RGBA, (0,1,2))

# Copy just the alpha channel, making a 1-channel image
Alpha = ImageBufAlgo.channels (RGBA, ("A",))

# Swap the R and B channels
BGRA = ImageBufAlgo.channels (RGBA, (2, 1, 0, 3))

# Add an alpha channel with value 1.0 everywhere to an RGB image
RGBA = ImageBufAlgo.channels (RGB, ("R", "G", "B", 1.0),
                              ("R", "G", "B", "A"))

ImageBuf ImageBufAlgo.channel_append (A, B, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.channel_append (dst, A, B, roi=ROI.All, nthreads=0)

Append the channels of images A and B together into one image.

Example:

RGBA = ImageBuf ("rgba.exr")
Z = ImageBuf ("z.exr")
RGBAZ = ImageBufAlgo.channel_append (RGBA, Z)

ImageBuf ImageBufAlgo.copy (src, convert=TypeDesc.UNKNOWN, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.copy (dst, src, convert=TypeDesc.UNKNOWN, roi=ROI.All, nthreads=0)

Copy the specified region of pixels of src at the same locations, optionally with the pixel type overridden by convert (if it is not UNKNOWN).

Example:

# Copy A's upper left 200x100 region into B
B = ImageBufAlgo.copy (A, ROI(0,200,0,100))

ImageBuf ImageBufAlgo.crop (src, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.crop (dst, src, roi=ROI.All, nthreads=0)

Reset dst to be the specified region of src.

Example:

# Set B to be the upper left 200x100 region of A
A = ImageBuf ("a.tif")
B = ImageBufAlgo.crop (A, ROI(0,200,0,100))

ImageBuf ImageBufAlgo.cut (src, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.cut (dst, src, roi=ROI.All, nthreads=0)

Reset dst to be the specified region of src, but moved so that the resulting new image has its pixel data at the image plane origin.

Example:

# Set B to be the lower left 200x100 region of A, moved to the origin
A = ImageBuf ("a.tif")
B = ImageBufAlgo.cut (A, ROI(0,200,380,480))

bool ImageBufAlgo.paste (dst, xbegin, ybegin, zbegin, chbegin, src, srcroi=ROI.All, nthreads=0)

Copy the specified region of src into dst with the given offset (xbegin, ybegin, zbegin).

Example:

# Paste small.exr on top of big.exr at offset (100,100)
Big = ImageBuf ("big.exr")
Small = ImageBuf ("small.exr")
ImageBufAlgo.paste (Big, 100, 100, 0, 0, Small)

ImageBuf ImageBufAlgo.rotate90 (src, roi=ROI.All, nthreads=0)

ImageBuf ImageBufAlgo.rotate180 (src, roi=ROI.All, nthreads=0)

ImageBuf ImageBufAlgo.rotate270 (src, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.rotate90 (dst, src, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.rotate180 (dst, src, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.rotate270 (dst, src, roi=ROI.All, nthreads=0)

Copy while rotating the image by a multiple of 90 degrees.

Example:

A = ImageBuf ("tahoe.exr")
B = ImageBufAlgo.rotate90 (A)

ImageBuf ImageBufAlgo.flip (src, roi=ROI.All, nthreads=0)

ImageBuf ImageBufAlgo.flop (src, roi=ROI.All, nthreads=0)

ImageBuf ImageBufAlgo.transpose (src, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.flip (dst, src, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.flop (dst, src, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.transpose (dst, src, roi=ROI.All, nthreads=0)

Copy while reversing orientation vertically (flip) or horizontally (flop), or diagonally (transpose).

Example:

A = ImageBuf ("tahoe.exr")
B = ImageBufAlgo.flip (A)

ImageBuf ImageBufAlgo.reorient (src, nthreads=0)

bool ImageBufAlgo.reorient (dst, src, nthreads=0)

Copy src, applying whatever seties of rotations, flips, or flops are necessary to transform the pixels into the configuration suggested by the "Orientation" metadata of the image (and the "Orientation" metadata is then set to 1, ordinary orientation).

Example:

A = ImageBuf ("tahoe.jpg")
ImageBufAlgo.reorient (A, A)

ImageBuf ImageBufAlgo.circular_shift (src, xshift, yshift, zshift=0, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.circular_shift (dst, src, xshift, yshift, zshift=0, roi=ROI.All, nthreads=0)

Copy while circularly shifting by the given amount.

Example:

A = ImageBuf ("tahoe.exr")
B = ImageBufAlgo.circular_shift (A, 200, 100)

ImageBuf ImageBufAlgo.rotate (src, angle, filtername="", filtersize=0.0, recompute_roi=False, roi=ROI.All, nthreads=0)

ImageBuf ImageBufAlgo.rotate (src, angle, center_x, center_y, filtername="", filtersize=0.0, recompute_roi=False, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.rotate (dst, src, angle, filtername="", filtersize=0.0, recompute_roi=False, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.rotate (dst, src, angle, center_x, center_y, filtername="", filtersize=0.0, recompute_roi=False, roi=ROI.All, nthreads=0)

Copy arotated version of the corresponding portion of src. The angle is in radians, with positive values indicating clockwise rotation. If the filter and size are not specified, an appropriate default will be chosen.

Example:

Src = ImageBuf ("tahoe.exr")
Dst = ImageBufAlgo.rotate (Src, math.radians(45.0))

ImageBuf ImageBufAlgo.warp (src, M, filtername="", filtersize=0.0, wrap="default", recompute_roi=False, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.warp (dst, src, M, filtername="", filtersize=0.0, wrap="default", recompute_roi=False, roi=ROI.All, nthreads=0)

Compute a warped (transformed) copy of src, with the warp specified by M consisting of 9 floating-point numbers representing a 3x3 transformation matrix. If the filter and size are not specified, an appropriate default will be chosen.

Example:

M = (0.7071068, 0.7071068, 0, -0.7071068, 0.7071068, 0, 20, -8.284271, 1)
Src = ImageBuf ("tahoe.exr")
Dst = ImageBufAlgo.warp (Src, M)

ImageBuf ImageBufAlgo.st_warp (src, M, filtername="", filtersize=0.0, wrap="default", recompute_roi=False, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.st_warp (dst, src, M, filtername="", filtersize=0.0, wrap="default", recompute_roi=False, roi=ROI.All, nthreads=0)

Example:

# distortion_st.tif is a map where every pixel value contains the 2D
# coordinate of where to copy from.
Distort = ImageBuf("distortion_st.tif")
Src = ImageBuf("tahoe.exr")
Dst = ImageBufAlgo.st_warp(Src, Distort)

ImageBuf ImageBufAlgo.resize (src, filtername="", filtersize=0.0, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.resize (dst, src, filtername="", filtersize=0.0, roi=ROI.All, nthreads=0)

Compute a high-quality resized version of the corresponding portion of src. If the filter and size are not specified, an appropriate default will be chosen.

Example:

# Resize the image to 640x480, using the default filter
Src = ImageBuf ("tahoe.exr")
Dst = ImageBufAlgo.resize (Src, roi=ROI(0,640,0,480,0,1,0,3))

ImageBuf ImageBufAlgo.resample (src, interpolate=True, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.resample (dst, src, interpolate=True, roi=ROI.All, nthreads=0)

Set dst, over the ROI, to be a low-quality (but fast) resized version of the corresponding portion of src, either using a simple “closest pixel” choice or by bilinaerly interpolating (depending on interpolate).

Example:

# Resample quickly to 320x240 to make a low-quality thumbnail
Src = ImageBuf ("tahoe.exr")
Dst = ImageBufAlgo.resample (Src, roi=ROI(0,640,0,480,0,1,0,3))

ImageBuf ImageBufAlgo.fit (src, filtername="", filtersize=0.0, fillmode="letterbox", exact=false, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.fit (dst, src, filtername="", filtersize=0.0, fillmode="letterbox", exact=false, roi=ROI.All, nthreads=0)

Fit src into the roi while preserving the original aspect ratio, without stretching. If the filter and size are not specified, an appropriate default will be chosen.

Example:

# Resize to fit into a max of 640x480, preserving the aspect ratio
Src = ImageBuf ("tahoe.exr")
Dst = ImageBufAlgo.fit (Src, roi=ROI(0,640,0,480,0,1,0,3))

Image arithmetic#

ImageBuf ImageBufAlgo.add (A, B, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.add (dst, A, B, roi=ROI.All, nthreads=0)

Compute A + B. A and B each may be an ImageBuf, a float value (for all channels) or a tuple giving a float for each color channel.

Example:

# Add two images
buf = ImageBufAlgo.add (ImageBuf("a.exr"), ImageBuf("b.exr"))

# Add 0.2 to channels 0-2
ImageBufAlgo.add (buf, buf, (0.2,0.2,0.2,0))

ImageBuf ImageBufAlgo.sub (A, B, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.sub (dst, A, B, roi=ROI.All, nthreads=0)

Compute A - B. A and B each may be an ImageBuf, a float value (for all channels) or a tuple giving a float for each color channel.

Example:

buf = ImageBufAlgo.sub (ImageBuf("a.exr"), ImageBuf("b.exr"))

ImageBuf ImageBufAlgo.absdiff (A, B, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.absdiff (dst, A, B, roi=ROI.All, nthreads=0)

Compute abs(A - B). A and B each may be an ImageBuf, a float value (for all channels) or a tuple giving a float for each color channel.

Example:

buf = ImageBufAlgo.absdiff (ImageBuf("a.exr"), ImageBuf("b.exr"))

ImageBuf ImageBufAlgo.abs (A, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.abs (dst, A, roi=ROI.All, nthreads=0)

Compute abs(A). A is an ImageBuf.

Example:

buf = ImageBufAlgo.abs (ImageBuf("a.exr"))

ImageBuf ImageBufAlgo.scale (A, B, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.scale (dst, A, B, roi=ROI.All, nthreads=0)

Per-pixel multiply all channels of one image by the single channle of the other image. One of the input images must have only one channel.

Example:

# Scale one image by the other
buf = ImageBufAlgo.scale (ImageBuf("a.exr"), ImageBuf("mono.exr"))

# Scale one image by the other, in place
ImageBufAlgo.scale (buf, buf, ImageBuf("mono.exr"))

ImageBuf ImageBufAlgo.mul (A, B, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.mul (dst, A, B, roi=ROI.All, nthreads=0)

Compute A * B (channel-by-channel multiplication). A and B each may be an ImageBuf, a float value (for all channels) or a tuple giving a float for each color channel.

Example:

# Multiply the two images
buf = ImageBufAlgo.mul (ImageBuf("a.exr"), ImageBuf("b.exr"))

# Reduce intensity of buf's channels 0-2 by 50%, in place
ImageBufAlgo.mul (buf, buf, (0.5, 0.5, 0.5, 1.0))

ImageBuf ImageBufAlgo.div (A, B, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.div (dst, A, B, roi=ROI.All, nthreads=0)

Compute A / B (channel-by-channel division), where x/0 is defined to be 0. A and B each may be an ImageBuf, a float value (for all channels) or a tuple giving a float for each color channel.

Example:

# Divide a.exr by b.exr
buf = ImageBufAlgo.div (ImageBuf("a.exr"), ImageBuf("b.exr"))

# Reduce intensity of buf's channels 0-2 by 50%, in place
ImageBufAlgo.div (buf, buf, (2.0, 2.0, 2.0, 1.0))

ImageBuf ImageBufAlgo.mad (A, B, C, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.mad (dst, A, B, C, roi=ROI.All, nthreads=0)

Compute A * B + C (channel-by-channel multiplication and addition). A, B, and C each may be an ImageBuf, a float value (for all channels) or a tuple giving a float for each color channel.

Example:

# Multiply a and b, then add c
buf = ImageBufAlgo.mad (ImageBuf("a.exr"),
                        (1.0f, 0.5f, 0.25f), ImageBuf("c.exr"))

ImageBuf ImageBufAlgo.invert (A, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.invert (dst, A, roi=ROI.All, nthreads=0)

Compute 1-A (channel by channel color inverse). A is an ImageBuf.

Example:

buf = ImageBufAlgo.invert (ImageBuf("a.exr"))

ImageBuf ImageBufAlgo.pow (A, B, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.pow (dst, A, B, roi=ROI.All, nthreads=0)

Compute pow (A, B) (channel-by-channel exponentiation). A is an ImageBuf, and B may be a float (a single power for all channels) or a tuple giving a float for each color channel.

Example:

# Linearize a 2.2 gamma-corrected image (channels 0-2 only)
img = ImageBuf ("a.exr")
buf = ImageBufAlgo.pow (img, (2.2, 2.2, 2.2, 1.0))

ImageBuf ImageBufAlgo.channel_sum (src, weights=(), roi=ROI.All, nthreads=0)

bool ImageBufAlgo.channel_sum (dst, src, weights=(), roi=ROI.All, nthreads=0)

Converts a multi-channel image into a 1-channel image via a weighted sum of channels. The weights is a tuple providing the weight for each channel (if not supplied, all channels will have weight 1.0).

Example:

# Compute luminance via a weighted sum of R,G,B
# (assuming Rec709 primaries and a linear scale)
ImageBuf()
weights = (.2126, .7152, .0722)
luma = ImageBufAlgo.channel_sum (ImageBuf("a.exr"), weights)

ImageBuf ImageBufAlgo.contrast_remap (src, black=0.0, white=1.0, min=0.0, max=1.0, sthresh=0.0, scontrast=1.0, ROI roi={}, int nthreads=0)

bool ImageBufAlgo.contrast_remap (ImageBuf &dst, src, black=0.0, white=1.0, min=0.0, max=1.0, sthresh=0.0, scontrast=1.0, ROI roi={}, int nthreads=0)

Return (or copy into dst) pixel values that are a contrast-remap of the corresponding values of the src image, transforming pixel value domain [black, white] to range [min, max], either linearly or with optional application of a smooth sigmoidal remapping (if scontrast != 1.0).

Example:

A = ImageBuf('tahoe.tif');

# Simple linear remap that stretches input 0.1 to black, and input
# 0.75 to white.
linstretch = ImageBufAlgo.contrast_remap (A, black=0.1, white=0.75)

# Remapping 0->1 and 1->0 inverts the colors of the image,
# equivalent to ImageBufAlgo.invert().
inverse = ImageBufAlgo.contrast_remap (A, black=1.0, white=0.0)

# Use a sigmoid curve to add contrast but without any hard cutoffs.
# Use a contrast parameter of 5.0.
sigmoid = ImageBufAlgo.contrast_remap (a, contrast=5.0)

ImageBuf ImageBufAlgo.saturate (src, scale=0.0, firstchannel=0, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.saturate (dst, src, scale=0.0, firstchannel=0, roi=ROI.All, nthreads=0)

Copy pixels from src to dst, and scale the saturation of channels firstchannel to firstchannel+2 by the scale factor.

This function was added in OpenImageIO 2.4.

Example:

# In-place reduce saturation by 50%
A = ImageBuf ("a.exr")
ImageBufAlgo.saturate (A, A, 0.5)

ImageBuf ImageBufAlgo.color_map (src, srcchannel, nknots, channels, knots, roi=ROI.All, nthreads=0)

ImageBuf ImageBufAlgo.color_map (src, srcchannel, mapname, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.color_map (dst, src, srcchannel, nknots, channels, knots, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.color_map (dst, src, srcchannel, mapname, roi=ROI.All, nthreads=0)

Return an image (or copy into dst) pixel values determined by applying the color map to the values of src, using either the channel specified by srcchannel, or the luminance of src’s RGB if srcchannel is -1.

In the first variant, the values linearly-interpolated color map are given by the tuple knots[nknots*channels].

In the second variant, just the name of a color map is specified. Recognized map names include: “inferno”, “viridis”, “magma”, “plasma”, all of which are perceptually uniform, strictly increasing in luminance, look good when converted to grayscale, and work for people with all types of colorblindness. The “turbo” color map is also nice in most of these ways (except for being strictly increasing in luminance). Also supported are the following color maps that do not have those desirable qualities (and are this not recommended): “blue-red”, “spectrum”, and “heat”. In all cases, the implied channels is 3.

Example:

heatmap = ImageBufAlgo.color_map (ImageBuf("a.jpg"), -1, "inferno")

heatmap = ImageBufAlgo.color_map (ImageBuf("a.jpg"), -1, 3, 3,
                        (0.25, 0.25, 0.25,  0, 0.5, 0,  1, 0, 0))

ImageBuf ImageBufAlgo.max (A, B, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.max (dst, A, B, roi=ROI.All, nthreads=0)

Compute per-pixel, per-channel max(A, B), returning the result image. At least one of A and B must be an ImageBuf, the other may also be an ImageBuf, or a float value (for all channels), or a tuple giving a float for each color channel.

Example:

# Make an image that for each pixel and channel, is the maximum
# value of that pixel and channel of A and B.
A = ImageBuf("a.exr")
B = ImageBuf("b.exr")
maximg = ImageBufAlgo.max (A, B)

# Do an in-place clamp image A so that all values are at least 0
# (thus ensuring that there are no negative values).
ImageBufAlgo.max (A, A, 0.0)

ImageBuf ImageBufAlgo.min (A, B, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.min (dst, A, B, roi=ROI.All, nthreads=0)

Compute per-pixel, per-channel min(A, B), returning the result image. At least one of A and B must be an ImageBuf, the other may also be an ImageBuf, or a float value (for all channels), or a tuple giving a float for each color channel.

Example:

# Make an image that for each pixel and channel, is the minimum
# value of that pixel and channel of A and B.
A = ImageBuf("a.exr")
B = ImageBuf("b.exr")
minimg = ImageBufAlgo.min (A, B)

# Do an in-place clamp image A so that the maximum value of each pixel
# is 0.5 (except for alpha, which may be up to 1.0):
ImageBufAlgo.min (A, A, (0.5, 0.5, 0.5, 1.0))

ImageBuf ImageBufAlgo.clamp (src, min, max, bool clampalpha01=False, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.clamp (dst, src, min, max, bool clampalpha01=False, roi=ROI.All, nthreads=0)

Copy pixels while clamping between the min and max values. The min and max may either be tuples (one min and max value per channel), or single floats (same value for all channels). Additionally, if clampalpha01 is True, then any alpha channel is clamped to the 0–1 range.

Example:

# Clamp image buffer A in-place to the [0,1] range for all channels.
ImageBufAlgo.clamp (A, A, 0.0, 1.0)

ImageBuf ImageBufAlgo.maxchan (src, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.maxchan (dst, src, roi=ROI.All, nthreads=0)

Return a one-channel image where each pixel has the maximum value found in any of the channels of src in that corresponding pixel.

This function was added in OpenImageIO 2.3.10.

Example:

A = ImageBuf("rgb.exr")
max_of_rgb = ImageBufAlgo.maxchan (A)

ImageBuf ImageBufAlgo.minchan (src, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.minchan (dst, src, roi=ROI.All, nthreads=0)

Return a one-channel image where each pixel has the minimum value found in any of the channels of src in that corresponding pixel.

This function was added in OpenImageIO 2.3.10.

Example:

A = ImageBuf("rgb.exr")
min_of_rgb = ImageBufAlgo.minchan (A)

ImageBuf ImageBufAlgo.rangecompress (src, useluma=False, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.rangecompress (dst, src, useluma=False, roi=ROI.All, nthreads=0)

ImageBuf ImageBufAlgo.rangeexpand (src, useluma=False, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.rangeexpand (dst, src, useluma=False, roi=ROI.All, nthreads=0)

Copy from src, compressing (logarithmically) or expanding (by the inverse of the compressive transformation) the range of pixel values. Alpha and z channels are copied but not transformed.

If useluma is True, the luma of the first three channels (presumed to be R, G, and B) are used to compute a single scale factor for all color channels, rather than scaling all channels individually (which could result in a big color shift when performing rangecompress and rangeexpand).

Example:

# Resize the image to 640x480, using a Lanczos3 filter, which
# has negative lobes. To prevent those negative lobes from
# producing ringing or negative pixel values for HDR data,
# do range compression, then resize, then re-expand the range.

# 1. Read the original image
Src = ImageBuf ("tahoeHDR.exr")

# 2. Range compress to a logarithmic scale
Compressed = ImageBufAlgo.rangecompress (Src)

# 3. Now do the resize
roi = ROI (0, 640, 0, 480, 0, 1, 0, Compressed.nchannels)
Dst = ImageBufAlgo.resize (Compressed, "lanczos3", 6.0, roi)

# 4. Expand range to be linear again (operate in-place)
ImageBufAlgo.rangeexpand (Dst, Dst)

ImageBuf ImageBufAlgo.over (A, B, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.over (dst, A, B, roi=ROI.All, nthreads=0)

Composite ImageBuf A over ImageBuf B.

Example:

Comp = ImageBufAlgo.over (ImageBuf("fg.exr"), ImageBuf("bg.exr"))

ImageBuf ImageBufAlgo.zover (A, B, bool z_zeroisinf=False, roi=ROI.All, nthreads=0

bool ImageBufAlgo.zover (dst, A, B, bool z_zeroisinf=False, roi=ROI.All, nthreads=0)

Composite ImageBuf A and ImageBuf B using their respective Z channels to decide which is in front on a pixel-by-pixel basis.

Example:

Comp = ImageBufAlgo.zover (ImageBuf("fg.exr"), ImageBuf("bg.exr"))

Image comparison and statistics#

PixelStats ImageBufAlgo.computePixelStats (src, roi=ROI.All, nthreads=0)

Compute statistics about the ROI of the image src. The PixelStats structure is defined as contining the following data fields: min, max, avg, stddev, nancount, infcount, finitecount, sum, sum2, each of which is a tuple with one value for each channel of the image.

Example:

A = ImageBuf("a.exr")
stats = ImageBufAlgo.computePixelStats (A)
print ("   min = ", stats.min)
print ("   max = ", stats.max)
print ("   average = ", stats.avg)
print ("   standard deviation  = ", stats.stddev)
print ("   # NaN values    = ", stats.nancount)
print ("   # Inf values    = ", stats.infcount)
print ("   # finite values = ", stats.finitecount)

CompareResults ImageBufAlgo.compare (A, B, failthresh, warnthresh, failrelative=0.0, warnrelative=0.0, roi=ROI.All, nthreads=0)

Numerically compare two ImageBuf’s, A and B. The failthresh and warnthresh supply absolute failure and warning difference thresholds, and failrelative and warnrelative supply failure and warning thresholds relative to the values in each image. The return value is a CompareResults object, which is defined as a class having the following members:

meanerror, rms_error, PSNR, maxerror  # error statistics
maxx, maxy, maxz, maxc                # pixel of biggest difference
nwarn, nfail                          # number of warnings and failures
error                                 # True if there was an error

Example:

A = ImageBuf ("a.exr")
B = ImageBuf ("b.exr")
comp = ImageBufAlgo.compare (A, B, 1.0/255.0, 0.0)
if comp.nwarn == 0 and comp.nfail == 0 :
    print ("Images match within tolerance")
else :
    print (comp.nfail, "failures,", comp.nwarn, " warnings.")
    print ("Average error was " , comp.meanerror)
    print ("RMS error was" , comp.rms_error)
    print ("PSNR was" , comp.PSNR)
    print ("largest error was ", comp.maxerror)
    print ("  on pixel", (comp.maxx, comp.maxy, comp.maxz))
    print ("  channel", comp.maxc)

tuple ImageBufAlgo.isConstantColor (src, threshold=0.0, roi=ROI.All, nthreads=0)

If all pixels of src within the ROI have the same values (for the subset of channels described by roi), return a tuple giving that color (one float for each channel), otherwise return None.

Example:

A = ImageBuf ("a.exr")
color = ImageBufAlgo.isConstantColor (A)
if color != None :
    print ("The image has the same value in all pixels:", color)
else :
    print ("The image is not a solid color.")

bool ImageBufAlgo.isConstantChannel (src, channel, val, threshold=0.0, roi=ROI.All, nthreads=0)

Returns True if all pixels of src within the ROI have the given channel value val.

Example:

A = ImageBuf ("a.exr")
alpha = A.spec.alpha_channel
if alpha < 0 :
    print ("The image does not have an alpha channel")
elif ImageBufAlgo.isConstantChannel (A, alpha, 1.0) :
    print ("The image has alpha = 1.0 everywhere")
else :
    print ("The image has alpha < 1 in at least one pixel")

bool ImageBufAlgo.isMonochrome (src, threshold=0.0, roi=ROI.All, nthreads=0)

Returns True if the image is monochrome within the ROI.

Example:

A = ImageBuf ("a.exr")
roi = A.roi
roi.chend = min (3, roi.chend)  # only test RGB, not alpha
if ImageBufAlgo.isMonochrome (A, roi) :
    print ("a.exr is really grayscale")

ImageBufAlgo.color_range_check(src, low, high, roi=ROI.All, nthreads=0)#

Count how many pixels in the src image (within the roi) are outside the value range described by low and hi (which each may be either one value or a tuple with per-channel values for each of roi.chbegin ... roi.chend. The result returned is a tuple containing three values: the number of values less than low, the number of values greater then hi, and the number of values within the range.

Example:

A = ImageBuf ("a.exr")
counts = ImageBufAlgo.color_range_check (A, 0.5, 0.75)
print ('{} values < 0.5, {} values > 0.75'.format(counts[0], counts[1]))

ROI ImageBufAlgo.nonzero_region (src, roi=ROI.All, nthreads=0)

Returns an ROI that tightly encloses the minimal region within roi that contains all pixels with nonzero values.

Example:

A = ImageBuf ("a.exr")
nonzero_roi = ImageBufAlgo.nonzero_region(A)

std::string ImageBufAlgo.computePixelHashSHA1 (src, extrainfo = "", roi=ROI.All, blocksize=0, nthreads=0)

Compute the SHA-1 byte hash for all the pixels in the ROI of src.

Example:

A = ImageBuf ("a.exr")
hash = ImageBufAlgo.computePixelHashSHA1 (A, blocksize=64)

tuple histogram (src, channel=0, bins=256, min=0.0, max=1.0, ignore_empty=False, roi=ROI.All, nthreads=0): Computes a histogram of the given channel of image src, within the ROI, returning a tuple of length bins containing count of pixels whose value was in each of the equally-sized range bins between min and max. If ignore_empty is True, pixels that are empty (all channels 0 including alpha) will not be counted in the total.

Convolutions#

ImageBuf ImageBufAlgo.make_kernel (name, width, height, depth=1.0, normalize=True)}

Create a 1-channel float image of the named kernel and dimensions. If normalize is True, the values will be normalized so that they sum to 1.0.

If depth > 1, a volumetric kernel will be created. Use with caution!

Kernel names can be: “gaussian”, “sharp-gaussian”, “box”, “triangle”, “mitchell”, “blackman-harris”, “b-spline”, “catmull-rom”, “lanczos3”, “cubic”, “keys”, “simon”, “rifman”, “disk”, “binomial”, “laplacian”. Note that “catmull-rom” and “lanczos3” are fixed-size kernels that don’t scale with the width, and are therefore probably less useful in most cases.

Example:

K = ImageBufAlgo.make_kernel ("gaussian", 5.0, 5.0)

ImageBuf ImageBufAlgo.convolve (src, kernel, normalize=True, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.convolve (dst, src, kernel, normalize=True, roi=ROI.All, nthreads=0)

Replace the given ROI of dst with the convolution of src and a kernel (also an ImageBuf).

Example:

# Blur an image with a 5x5 Gaussian kernel
Src = ImageBuf ("tahoe.exr")
K = ImageBufAlgo.make_kernel (K, "gaussian", 5.0, 5.0)
Blurred = ImageBufAlgo.convolve (Src, K)

ImageBuf ImageBufAlgo.laplacian (src, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.laplacian (dst, src, roi=ROI.All, nthreads=0)

Replace the given ROI of dst with the Laplacian of the corresponding part of src.

Example:

Src = ImageBuf ("tahoe.exr")
L = ImageBufAlgo.laplacian (Src)

ImageBuf ImageBufAlgo.fft (src, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.fft (dst, src, roi=ROI.All, nthreads=0)

ImageBuf ImageBufAlgo.ifft (src, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.ifft (dst, src, roi=ROI.All, nthreads=0)

Compute the forward or inverse discrete Fourier Transform.

Example:

Src = ImageBuf ("tahoe.exr")

# Take the DFT of the first channel of Src
Freq = ImageBufAlgo.fft (Src)

# At this point, Freq is a 2-channel float image (real, imag)
# Convert it back from frequency domain to a spatial image
Spatial = ImageBufAlgo.ifft (Freq)

ImageBuf ImageBufAlgo.complex_to_polar (src, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.complex_to_polar (dst, src, roi=ROI.All, nthreads=0)

ImageBuf ImageBufAlgo.polar_to_complex (src, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.polar_to_complex (dst, src, roi=ROI.All, nthreads=0)

Transform a 2-channel image from complex (real, imaginary) representation to polar (amplitude, phase), or vice versa.

Example:

Polar = ImageBuf ("polar.exr")

Complex = ImageBufAlgo.polar_to_complex (Polar)

# At this point, Complex is a 2-channel complex image (real, imag)
# Convert it back from frequency domain to a spatial image
Spatial = ImageBufAlgo.ifft (Complex)

Image Enhancement / Restoration#

ImageBuf ImageBufAlgo.fixNonFinite (src, mode=NONFINITE_BOX3, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.fixNonFinite (dst, src, mode=NONFINITE_BOX3, roi=ROI.All, nthreads=0)

Copy pixel values from src and repair any non-finite (NaN or Inf) pixels.

How the non-finite values are repaired is specified by one of the following modes:

OpenImageIO.NONFINITE_NONE
OpenImageIO.NONFINITE_BLACK
OpenImageIO.NONFINITE_BOX3

Example:

Src = ImageBuf ("tahoe.exr")
ImageBufAlgo.fixNonFinite (Src, Src, OpenImageIO.NONFINITE_BOX3)

ImageBuf ImageBufAlgo.fillholes_pushpull (src, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.fillholes_pushpull (dst, src, roi=ROI.All, nthreads=0)

Copy the specified ROI of src and fill any holes (pixels where alpha < 1) with plausible values using a push-pull technique. The src image must have an alpha channel. The dst image will end up with a copy of src, but will have an alpha of 1.0 everywhere, and any place where the alpha of src was < 1, dst will have a pixel color that is a plausible “filling” of the original alpha hole.

Example:

Src = ImageBuf ("holes.exr")
Filled = ImageBufAlgo.fillholes_pushpull (Src)

bool ImageBufAlgo.median_filter (dst, src, width=3, height=-1, roi=ROI.All, nthreads=0)

Replace the given ROI of dst with the width x height median filter of the corresponding region of src using the “unsharp mask” technique.

Example:

Noisy = ImageBuf ("tahoe.exr")
Clean = ImageBuf ()
ImageBufAlgo.median_filter (Clean, Noisy, 3, 3)

ImageBuf ImageBufAlgo.dilate (src, width=3, height=-1, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.dilate (dst, src, width=3, height=-1, roi=ROI.All, nthreads=0)

ImageBuf ImageBufAlgo.erode (src, width=3, height=-1, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.erode (dst, src, width=3, height=-1, roi=ROI.All, nthreads=0) }

Compute a dilated or eroded version of the corresponding region of src.

Example:

Source = ImageBuf ("source.tif")
Dilated = ImageBufAlgo.dilate (Source, 3, 3)

ImageBuf ImageBufAlgo.unsharp_mask (src, kernel="gaussian", width=3.0, contrast=1.0, threshold=0.0, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.unsharp_mask (dst, src, kernel="gaussian", width=3.0, contrast=1.0, threshold=0.0, roi=ROI.All, nthreads=0)

Compute a sharpened version of the corresponding region of src using the “unsharp mask” technique.

Example:

Blurry = ImageBuf ("tahoe.exr")
Sharp = ImageBufAlgo.unsharp_mask (Blurry, "gaussian", 5.0)

Color manipulation#

ImageBuf ImageBufAlgo.colorconvert (src, fromspace, tospace, unpremult=True, context_key="", context_value="", colorconfig="", roi=ROI.All, nthreads=0)

bool ImageBufAlgo.colorconvert (dst, src, fromspace, tospace, unpremult=True, context_key="", context_value="", colorconfig="", roi=ROI.All, nthreads=0)

Apply a color transform to the pixel values.

Example:

Src = ImageBuf ("tahoe.jpg")
Dst = ImageBufAlgo.colorconvert (Src, "sRGB", "scene_linear")

ImageBuf ImageBufAlgo.colormatrixtransform (src, M, unpremult=True, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.colormatrixtransform (dst, src, M, unpremult=True, roi=ROI.All, nthreads=0)

NEW in 2.1

Apply a 4x4 matrix color transform to the pixel values. The matrix can be any tuple of 16 float values.

Example:

Src = ImageBuf ("tahoe.jpg")
M = ( .8047379,  .5058794, -.3106172, 0,
     -.3106172,  .8047379,  .5058794, 0,
      .5058794, -.3106172,  .8047379, 0,
      0,         0,         0,       1)
Dst = ImageBufAlgo.colormatrixtransform (Src, M)

ImageBuf ImageBufAlgo.ociolook (src, looks, fromspace, tospace, unpremult=True, inverse=False, context_key="", context_value="", colorconfig="", roi=ROI.All, nthreads=0)

bool ImageBufAlgo.ociolook (dst, src, looks, fromspace, tospace, unpremult=True, inverse=False, context_key="", context_value="", colorconfig="", roi=ROI.All, nthreads=0)

Apply an OpenColorIO “look” transform to the pixel values.

Example:

Src = ImageBuf ("tahoe.jpg")
Dst = ImageBufAlgo.ociolook (Src, "look", "vd8", "lnf",
                        context_key="SHOT", context_value="pe0012")

ImageBuf ImageBufAlgo.ociodisplay (src, display, view, fromspace="", looks="", unpremult=True, inverse=False, context_key="", context_value="", colorconfig="", roi=ROI.All, nthreads=0)

bool ImageBufAlgo.ociodisplay (dst, src, display, view, fromspace="", looks="", unpremult=True, inverse=False, context_key="", context_value="", colorconfig="", roi=ROI.All, nthreads=0)

Apply an OpenColorIO “display” transform to the pixel values.

Example:

Src = ImageBuf ("tahoe.exr")
Dst = ImageBufAlgo.ociodisplay (Src, "sRGB", "Film", "lnf",
                          context_key="SHOT", context_value="pe0012")

ImageBuf ImageBufAlgo.ociofiletransform (src, name, unpremult=True, inverse=False, colorconfig="", roi=ROI.All, nthreads=0)

bool ImageBufAlgo.ociofiletransform (dst, src, name, unpremult=True, inverse=False, colorconfig="", roi=ROI.All, nthreads=0)

Apply an OpenColorIO “file” transform to the pixel values. In-place operations (dst and src being the same image) are supported.

Example:

Src = ImageBuf ("tahoe.exr")
Dst = ImageBufAlgo.ociofiletransform (Src, "foottransform.csp")

ImageBuf ImageBufAlgo.ocionamedtransform (src, name, unpremult=True, inverse=False, context_key="", context_value="", colorconfig="", roi=ROI.All, nthreads=0)

bool ImageBufAlgo.ocionamedtransform (dst, src, name, unpremult=True, inverse=False, context_key="", context_value="", colorconfig="", roi=ROI.All, nthreads=0)

Apply an OpenColorIO “named” transform to the pixel values.

Example:

Src = ImageBuf ("tahoe.dpx")
Dst = ImageBufAlgo.ocionamedtransform (Src, "log_to_lin",
                        context_key="SHOT", context_value="pe0012")

ImageBuf ImageBufAlgo.unpremult (src, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.unpremult (dst, src, roi=ROI.All, nthreads=0)

ImageBuf ImageBufAlgo.premult (src, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.premult (dst, src, roi=ROI.All, nthreads=0)

ImageBuf ImageBufAlgo.repremult (src, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.repremult (dst, src, roi=ROI.All, nthreads=0)

Copy pixels from src to dst, and un-premultiply, premultiply, or re-premultiply the colors by alpha.

unpremult divides colors by alpha, but preserves original color if alpha is 0. premult multiplies colors by alpha (even if alpha is 0). repreumlt is the true inverse of unpremult, multiplying color by alpha, but preserving color values in the alpha = 0 case.

Example:

# Convert in-place from associated alpha to unassociated alpha
A = ImageBuf ("a.exr")
ImageBufAlgo.unpremult (A, A)

ImageBuf ImageBufAlgo.demosaic (src, pattern="", algorithm="", layout="", white_balance=py::none(), roi=ROI.All, nthreads=0)

bool ImageBufAlgo.demosaic (dst, src, pattern="", algorithm="", layout="", white_balance=py::none(), roi=ROI.All, nthreads=0)

Demosaic a raw digital camera image.

demosaic can currently process Bayer pattern images (pattern=”bayer”) using two algorithms: “linear” (simple bilinear demosaicing), and “MHC” (Malvar-He-Cutler algorithm). The optional white_balance parameter can take a tuple of three (R,G,B), or four (R,G1,B,G2) values. The order of the white balance multipliers is as specified, it does not depend on the matrix layout.

Example:

Src = ImageBuf("test.cr3", 0, 0, hint)
WB_RGBG = (2.0, 0.8, 1.5, 1.2)
Dst = OpenImageIO.ImageBufAlgo.demosaic(Src, layout="GRBG",
    white_balance = WB_RGBG)

Import / export#

bool ImageBufAlgo.make_texture (mode, input, outputfilename, config=ImageSpec())

Turn an input image (either an ImageBuf or a string giving a filename) into a tiled, MIP-mapped, texture file and write to the file named by (outputfilename). The mode describes what type of texture file we are creating and may be one of the following:

OpenImageIO.MakeTxTexture
OpenImageIO.MakeTxEnvLatl
OpenImageIO.MakeTxEnvLatlFromLightProbe

The config, if supplied, is an ImageSpec that contains all the information and special instructions for making the texture. The full list of supported configuration options is given in Section Import / export.

The return value is True for success, False if errors occurred, in which case the error message will be retrievable from the global oiio.geterror().

Example:

# This command line:
#    maketx in.exr --hicomp --filter lanczos3 --opaque-detect \
#             -o texture.exr
# performs the same operations as:

import OpenImageIO as oiio

Input = oiio.ImageBuf ("in.exr")
config = oiio.ImageSpec()
config.attribute ("maketx:highlightcomp", 1)
config.attribute ("maketx:filtername", "lanczos3")
config.attribute ("maketx:opaque_detect", 1)
ok = oiio.ImageBufAlgo.make_texture (oiio.MakeTxTexture, Input,
                                "texture.exr", config)
if not ok :
    print("error:", oiio.geterror())

Functions specific to deep images#

ImageBuf ImageBufAlgo.deepen (src, zvalue=1.0, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.deepen (dst, src, zvalue=1.0, roi=ROI.All, nthreads=0)

Convert a flat image to a deep one that has one depth sample per pixel (but no depth samples for the pixels corresponding to those in the source image that have infinite “Z” or that had 0 for all color channels and no “Z” channel).

Example:

Deep = ImageBufAlgo.deepen (ImageBuf("az.exr"))

ImageBuf ImageBufAlgo.flatten (src, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.flatten (dst, src, roi=ROI.All, nthreads=0)

Composite the depth samples within each pixel of “deep” ImageBuf src to produce a “flat” ImageBuf.

Example:

Flat = ImageBufAlgo.flatten (ImageBuf("deepalpha.exr"))

ImageBuf ImageBufAlgo.deep_merge (A, B, occlusion_cull, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.deep_merge (dst, A, B, occlusion_cull, roi=ROI.All, nthreads=0)

Merge the samples of two deep images A and B into a deep result. If occlusion_cull is True, samples beyond the first opaque sample will be discarded, otherwise they will be kept.

Example:

DeepA = ImageBuf("hardsurf.exr")
DeepB = ImageBuf("volume.exr")
Merged = ImageBufAlgo.deep_merge (DeepA, DeepB)

ImageBuf ImageBufAlgo.deep_holdout (src, holdout, roi=ROI.All, nthreads=0)

bool ImageBufAlgo.deep_holdout (dst, src, holdout, roi=ROI.All, nthreads=0)

Return the pixels of src, but only copying the samples that are closer than the opaque frontier of image holdout. That is, holdout will serve as a depth holdout mask, but no samples from holdout will actually be copied to dst.

Example:

Img = ImageBuf("image.exr")
Mask = ImageBuf("mask.exr")
Thresholded = ImageBufAlgo.deep_holdout (Img, Mask)

Other ImageBufAlgo methods that understand deep images#

In addition to the previously described methods that are specific to deep images, the following ImageBufAlgo methods (described in their respective sections) work with deep inputs:

ImageBufAlgo.add
ImageBufAlgo.channels
ImageBufAlgo.compare
ImageBufAlgo.computePixelStats
ImageBufAlgo.crop
ImageBufAlgo.div
ImageBufAlgo.fixNonFinite
ImageBufAlgo.mul
ImageBufAlgo.nonzero_region
ImageBufAlgo.resample
ImageBufAlgo.sub

Miscellaneous Utilities#

In the main OpenImageIO module, there are a number of values and functions that are useful. These correspond to the C++ API functions explained in Section Global Attributes, please refer there for details.

openimageio_version#: The OpenImageIO version number is an int, 10000 for each major version, 100 for each minor version, 1 for each patch. For example, OpenImageIO 1.2.3 would return a value of 10203.

geterror(clear=True)#: Retrieves the latest global error, as a string.

attribute(name, typedesc, value)#

attribute(name, int_value)

attribute(name, float_value)

attribute(name, str_value)

Sets a global attribute (see Section Global Attributes for details), returning True upon success, or False if it was not a recognized attribute.

Example:

oiio.attribute ("threads", 0)

getattribute(name, typedesc)#

get_int_attribute(name, defaultval=0)#

get_float_attribute(name, defaultval=0.0)#

get_string_attribute(name, defaultval='')#

get_bytes_attribute(name, defaultval='')#

Retrieves an attribute value from the named set of global OIIO options. (See Section Global Attributes.) The getattribute() function returns the value regardless of type, or None if the attribute does not exist. The typed variety will only succeed if the attribute is actually of that type specified. Type variety with the type in the name also takes a default value.

For an attribute of type STRING, get_bytes_attribute in Python3 skips decoding the underlying C string as UTF-8 and returns a bytes object containing the raw byte string.

Example:

formats = oiio.get_string_attribute ("format_list")

set_colorspace(spec, name)#

Set the metadata of the spec to presume that color space is name (or to assume nothing about the color space if name is empty).

Example:

spec = oiio.ImageSpec()
oiio.set_colorspace (spec, "lin_rec709")

This function was added in OpenImageIO 3.0.

set_colorspace_rec709_gamma(spec, name)#

Set the metadata of the spec to reflect Rec709 color primaries and the given gamma.

Example:

spec = oiio.ImageSpec()
oiio.set_colorspace_rec709_gamma (spec, 2.2)

This function was added in OpenImageIO 3.0.

equivalent_colorspace(a, b)#

Return True if the color spaces a and b are equivalent in the default active color config.

Example:

# ib is an ImageBuf
cs = ib.spec().get_string_attribute("oiio:ColorSpace")
if oiio.equivalent_colorspace(cs, "sRGB") :
    print ("The image is sRGB")

This function was added in OpenImageIO 3.0.

is_imageio_format_name(name)#

Returns True if name is the name of a known and supported file format, False if it is not.

Example:

>>> print (oiio.is_imageio_format_name('tiff'))
True
>>> print (oiio.is_imageio_format_name('Bob'))
False

Python Recipes#

This section illustrates the Python syntax for doing many common image operations from Python scripts, but that aren’t already given as examples in the earlier function descriptions. All example code fragments assume the following boilerplate:

#!/usr/bin/env python

import OpenImageIO as oiio
from OpenImageIO import ImageBuf, ImageSpec, ImageBufAlgo

Subroutine to create a constant-colored image

# Create an ImageBuf holding a n image of constant color, given the
# resolution, data format (defaulting to UINT8), fill value, and image
# origin.
def make_constimage (xres, yres, chans=3, format=oiio.UINT8, value=(0,0,0),
                     xoffset=0, yoffset=0) :
    spec = ImageSpec (xres,yres,chans,format)
    spec.x = xoffset
    spec.y = yoffset
    b = ImageBuf (spec)
    oiio.ImageBufAlgo.fill (b, value)
    return b

The image is returned as an ImageBuf, then up to the caller what to do with it next.

Subroutine to save an image to disk, printing errors

# Save an ImageBuf to a given file name, with optional forced image format
# and error handling.
def write_image (image, filename, format=oiio.UNKNOWN) :
    if not image.has_error :
        image.write (filename, format)
    if image.has_error :
        print ("Error writing", filename, ":", image.geterror())

Converting between file formats

img = ImageBuf ("input.png")
write_image (img, "output.tif")

Comparing two images and writing a difference image

A = ImageBuf ("A.tif")
B = ImageBuf ("B.tif")
compresults = ImageBufAlgo.compare (A, B, 1.0e-6, 1.0e-6)
if compresults.nfail > 0 :
    print ("Images did not match, writing difference image diff.tif")
    diff = ImageBufAlgo.absdiff (A, B)
    image_write (diff, "diff.tif")

Changing the data format or bit depth

img = ImageBuf ("input.exr")
# presume that it's a "half" OpenEXR file
# write it back out as a "float" file:
write_image (img, "output.exr", oiio.FLOAT)

Changing the compression

The following command converts writes a TIFF file, specifically using LZW compression:

img = ImageBuf ("in.tif")
img.specmod().attribute ("compression", "lzw")
write_image (img, "compressed.tif")

The following command writes its results as a JPEG file at a compression quality of 50 (pretty severe compression):

img = ImageBuf ("big.jpg")
img.specmod().attribute ("quality", 50)
write_image (img, "small.jpg")

Converting between scanline and tiled images

img = ImageBuf ("scan.tif")
img.set_write_tiles (64, 64)
write_image (img, "tile.tif")

img = ImageBuf ("tile.tif")
img.set_write_tiles (0, 0)
write_image (img, "scan.tif")

Adding captions or metadata

img = ImageBuf ("foo.jpg")
# Add a caption:
img.specmod().attribute ("ImageDescription", "Hawaii vacation")
# Add keywords:
img.specmod().attribute ("keywords", "volcano,lava")
write_image (img, "foo.jpg")

Changing image boundaries

Change the origin of the pixel data window:

img = ImageBuf ("in.exr")
img.set_origin (256, 80)
write_image (img, "offset.exr")

Change the display window:

img = ImageBuf ("in.exr")
img.set_full (16, 1040, 16, 784)
write_image (img, "out.exr")

Change the display window to match the data window:

img = ImageBuf ("in.exr")
img.set_full (img.roi())
write_image (img, "out.exr")

Cut (trim and extract) a 128x128 region whose upper left corner is at location (900,300), moving the result to the origin (0,0) of the image plane and setting the display window to the new pixel data window:

img = ImageBuf ("in.exr")
b = ImageBufAlgo.cut (img, oiio.ROI(900,1028,300,428))
write_image (b, "out.exr")

Extract just the named channels from a complicted many-channel image, and add an alpha channel that is 1 everywhere

img = ImageBuf ("allmyaovs.exr")
b = ImageBufAlgo.channels (img, ("spec.R", "spec.G", "spec.B", 1.0))
write_image (b, "spec.tif")

Fade 30% of the way between two images

a = ImageBufAlgo.mul (ImageBuf("A.exr"), 0.7)
b = ImageBufAlgo.mul (ImageBuf("B.exr"), 0.3)
fade = ImageBufAlgo.add (a, b)
write_image (fade, "fade.exr")

Composite of small foreground over background, with offset

fg = ImageBuf ("fg.exr")
fg.set_origin (512, 89)
bg = ImageBuf ("bg.exr")
comp = ImageBufAlgo.over (fg, bg)
write_image (comp, "composite.exr")

Write multiple ImageBufs into one multi-subimage file

bufs = (...)   # Suppose that bufs is a tuple of ImageBuf
specs = (...)  # specs is a tuple of the specs that describe them

# Open with intent to write the subimages
out = ImageOutput.create ("multipart.exr")
out.open ("multipart.exr", specs)
for s in range(len(bufs)) :
    if s > 0 :
        out.open ("multipart.exr", specs[s], "AppendSubimage")
    bufs[s].write (out)
out.close ()
